Foam Sheet Extrusion Machine for Polystyrene Packaging Production

Product Description

PS Foam Sheet Extruder Machine
The PS foam sheet extruder is the cornerstone of creating an array of final products. This essential machinery initiates the production process with precision and reliability, ensuring quality and efficiency from the very beginning.
As leaders in the PS foam sheet industry in China, we possess unparalleled expertise and extensive experience in meeting diverse customer requirements. Our primary market focuses on
the South America region. We eagerly invite you to discuss your specific needs with us and visit our state-of-the-art factory.
Machine Features: - Precision-engineered screw
- Outfitted with highly accurate extrusion components
- Specially designed rear section of the secondary extruder to prevent any leakage
- Computer-controlled cooling water system for optimal performance of the secondary extruder - Unique die and air ring ensuring consistent thickness and superior sheet quality - Capability to store all technical parameters for repeatable excellence
Model Parameters Unit HLSJPS-130/170
Capacity kg/hr 450-550
Thickness mm 1.5-6
Sheet Width mm Double sheet 1000-1500
Foam Rate times 11-30
Density kg/m
332.5-90
L/D 37/1, 38/1
Cooling Air cooling for the primary extruder, water cooling for the secondary extruder
Linear Speed m/min 5-40
Central Height mm 1100
Cooling Water Pressure Mpa ≥0.3
Cooling Water Volume t/h 20
Compressed Air Pressure Mpa 0.7-0.9
Compressed Air Volume m
3/min 2
Butane Gas Pressure Mpa 1
Installed Power kw 625
Installed Size m 40x4.5x3
Weight t 32
