Fold Wing Heavy Duty Disc Harrow
| Negotiable | 1 Piece (MOQ) |
Basic Info.
Model NO.
1BZDZ-4.4
Farming Policy
Dry Cultivating Machinery
Power Source
Tractor
Operation
Soil Preparation Machinery, Movable Operation
Traction Type
Traction
Drive Type
Trailed
Arbor Configuration
Vertical Shaft
Color
Green/Yellow/Blue
Model
1bzdz-4.4
Weight
3100
Working Width
4.4
Working Depth
25
Blade Spacing
230
No of Disc
40
Dia.of Disc
660
Productivity
4
Linkage
Trailed
Transport Package
Iron Frame Box
Specification
CE, RoHS, SGS, GMP
Trademark
DADI
Origin
Shandong Yucheng
HS Code
8433110000
Production Capacity
10000PC/Year
Product Description
1BZDZ series wing-folded heavy-duty disc harrow are mainly used for cleaning away stuble of plants before tillage,or crushing clods after tillage on uncultivated land and in sticky heavy clay soil fields,they can also be used as a plough for primary tillage in dry culdtivated fields. The series produced are all fitted with hydraulic rubber wheel for transportation.It is easy to be transported and change direction on the edge of fields.Specifications:
| Model | Unit | 1BZDZ-4.4 | 1BZDZ-4.8 | 1BZDZ-5.3 |
| Overall dimension | cm | 580x450x150 | 580x495x150 | 580x540x150 |
| Weight | kg | 3100-3150 | 3250-3300 | 3400-3450 |
| Working width | m | 4.4 | 4.8 | 5.3 |
| Working depth | cm | 20 | ||
| Blade spacing | mm | 230 | ||
| No of disc | pc | 40 | 44 | 48 |
| Dia.of disc | mm | 660 | ||
| Transport clearance | mm | >260 | ||
| Productivity | ha/h | 4.4 | 4.8 | 5.3 |
| Matched power | kw | 105-110 | 115-120 | 125-130 |
| Linkage | Trailed | |||
