Hot Sale High Capacity Efficiency Adjustable Mining Vibrating Feeder

Product Description

Product Introduction
ZSW Series Vibrating Feeder is designed based on principle that spinning of two synchronous eccentric shafts producing vibrating force. It's mainly used for continuous feeding before coarse crushing, at the same time, screening the materials according to the preset bars gap to improve the crushing efficiency. The feeder is widely used for feeding and crushing processing work of industrial mineral raw material and several kinds of rocks in building aggregate production, metallurgy, mine, building material, chemical industry and many other industries.
Product Features
1. Simple structure, even feeding, good continuous performance, adjustable exciting force.
2. Stable amplitude, reliable running, strong adaptation to various materials.
3. Adopt steel spring support and vibration isolation, which can withstand greater impact loads, smooth operation and start-stop, low noise, long lifetime.
4. The feed capacity is controllable by adjusting frequency with frequency conversion controller, no need to start motor frequently.
5. According to different materials, blind plate or steel plate mesh is optional for different working conditions.
6. The screening layers can be added under the pre-screening bars according to customers' needs (requirements), which can further classified and separated the pre-screening materials, also can add high weir plate or liner plate.
Technical Parameters

Model	Max. Feed Size (mm)	Speed (r/min)	Capacity (t/h)	Power (kw)	Dimension (mm)
ZSW380×95	500	500-800	90-150	11	3970×2259×1880
ZSW420×110	580	500-800	150-280	15	4392×2519×2003
ZSW490×110	580	500-800	150-350	18..5	5093×2524×2014
ZSW600×130	750	500-800	220-560	30	6124×2863×2051
ZSW600×150	900	500-800	260-620	37	6271×2369×2698
ZSW600×180	1050	600-850	400-1000	45	6375×2653×2913
ZSW600×210	1200	600-850	550-1250	45	6417×2880×3159
