Integrated All-in-One Outdoor Lamparas-Solaraes Solar Power LED Garden Light with Smart Pole
| US$100.00-250.00 | 2 Pieces (MOQ) |
Basic Info.
Model NO.
YD-TYN
Light Source
LED Lamp
Lamp Body Material
Aluminum
Light Type
Solar
Color Temperature
Cool White
Power
≥30W
Technics
Electroplating
Illumination Time
12h
Cell Type
Lithium Battery
Charging Time (H)
4
Usage
Garden, Street, Road
IP Rating
IP65
Certification
CE
Voltage
12/24V
With Light Source
With Light Source
Battery
Li Battery
LED Power
30W/40W/50W/60W/80W/100W/150W/200W
Solar Panel
Monocrystalline Solar Panel
Working Mode
Daylight Control + Remote Control
Keyword
Solar LED Street Light Lamp
Type
Outdoor Solar LED Streetlight
Material
Aluminium Alloy + Tempered Glass
Solar Panel Power
30-150W
Application
Solar Street Light
Pole′s Height
6-12m
Transport Package
Paper Box
Specification
10W/20W/30W/40W/50W/60W/80W/90W/100W/120W
Trademark
Quicklite
Origin
Yangzhou Jiangsu
HS Code
9405409000
Production Capacity
5000 Piece/Pieces Per Month
Packaging & Delivery
Package Size
120.00cm * 100.00cm * 100.00cm
Package Gross Weight
150.000kg
Product Description
Product DescriptionProduct Parameters
| Product Type | All In One Solar Street Light | |||||
| Model | 30w | 40W | 60W | 80W | 100W | 120W |
| LED Brand | 3030 | 3030 | 3030 | 3030 | 3030 | 3030 |
| LED QTY(PCS) | 72 | 108 | 144 | 256 | 256 | 384 |
| Power of PV Module | 18V 60W | 18V 70W | 18W 90W | 18V 110W | 36V 12W | 36V 160W |
| LiFePO4 Battery | 12.8v 380wh | 12.8v 460.8wh | 12.8v 537.6wh | 25.6v 768wh | 25.6v 921.6wh | |
| Light Mode | PIR/Time Control | Time Control | ||||
| Product Weight | 12KG | 14KG | 17KG | 22KG | 24KG | 32.8KG |
| Product Size(mm) | 753*373*60 | 893*373*60 | 1123*373*60 | 1173*423*60 | 1413*423*60 | 1713*373*60 |
| Light Parameter | ||||||
| Light Powder | 30W | 40W | 60W | 80W | 100W | 120W |
| Tyical Liminous Flux(lm) | 5400 | 7200 | 10800 | 14400 | 18000 | 21600 |
| LED Light Effect | 200lm/w | |||||
| Color Temperature | 2700-6500 | |||||
| Beam Angle | 150°*80° | |||||
| Warranty | 5 Years | |||||
| Environment Parameter | ||||||
| Charging Temperature | 0ºC to +60ºC | |||||
| Discharging Temperature | -20ºC to 60ºC | |||||
| Storage Temperature | -20ºC to 45ºC | |||||
| Installations | ||||||
| Dia.of Top Pole | 50-60mm | 70-80mm | 90-100mm | |||
| Installation Height | 4-6m | 5-7m | 6-8m | 8-10m | 9-11m | 10-12m |
| Installation Distance | 15-25m | 20-30m | 25-35m | 30-40m | 35-45m | 40-50m |
| 1.First integrated design, simple, fashionable, light and practical. 2.Solar power is used to save energy and protect the earth's resources. 3.Adopt the infrared induction control technology of the human body, people come to light, people walk the lamp dark, extend the lighting time; 4.Adopt high capacity long life lithium battery to ensure the service life of the product. 5.No need to pull wires, installation is very convenient. 6.Waterproof structure, safe and reliable; 7.Extensible timing, voice control and other functions. 8.Adopt modular design concept to facilitate installation, maintenance and repair. 9.Alloy material is used as the main body of the structure. It has good functions of rust prevention and corrosion prevention |
FAQ
FAQ Q: What if my home's electricity needs change over time?
A:SimpliPhi's batteries are uniquely modular and scalable. That means your energy storage system can be sized to match and optimize your electrical loads as your home, family or lifestyle changes. If your energy usage increases with time you can easily and seamlessly add more PHI batteries to your existing storage bank. Q:Are you a manufacturer or a trade company?
A:We are a large professional manufacturer, specializing in making street lights, street light poles, and various lamps.
Q:How much is the freight cost of samples?
A:It's depends on weight, packing size and destination. Please contact us if you need, we can
get the quote for you.
Q:How do your factory control quality?
A:We have 4 times inspection by QC before shipping. The first time is for raw material, the
second and third times are for appearance and function, and the final is for packing.
Q:What is the lead time?
A:20 days after receiving the 30% deposit.
Q:What is the shipping method?
A:It could be shipped by sea, by air or by express.(EMS,UPS,DHL,TNT,FEDEX and etc.)Please
confirm with us before placing orders.
Q:What is the payment terms?
A:T/T,L/C,Western Union is available. Please contact us.
Q:What is the payment condition?
A:30% deposit to confirm the order,70% balance before the shipment.
