Aoda 100L Laboratory Large Vessel Jacket Glass Reactor
| US$2,500.00-5,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
AGRL-100L
Type
Tank Reactor
Material
Glass-Lined
Capacity
<50L
Structure
Filling Tube
Pressure
Negative
Agitator Model
Anchor Agitator
Tower Reactor Type
Plate Tower Reactor
Heating
Oil Circulation Heating
Heat Transfer Structure
Jacketed
Automatic Grade
Automatic
Condition
New
Product Name
100L Laboratory Large Vessel Jacket Glass Reactor
Volume
100L
Jacket Volume
30L
Conderser Cooling Area
0.4m2
Constant Pressure Funnel Volume
2L
Reflux Bottle Volume
1L
Stirring Speed
0-450rpm
Stirring Power
200W
Ultra Pressure
-0.098MPa
Glass Material
High Borosilicate 3.3
Frame Material
SUS304
Temperature
-80~200c
Agitator Material
Stainless Steel,Add PTFE Layer
Power Supply
220-240V50Hz;1110V60Hz
Size
95*78*280cm
Transport Package
Wooden Case
Specification
60*50*160cm
Trademark
AODA
Origin
China
HS Code
8419899090
Production Capacity
100PCS a Month
Product Description
Aoda 100L Laboratory large vessel Jacket glass reactorThe Glass reactor is a container used for reaction. The inner container is cooled and heated by using coolant and heating liquid, and the temperature of the reaction materials in the inner container is controlled by the jacket design, so that the inner materials of the reactor react at the required temperature. At the same time, different functions such as adding materials, measuring temperature, and recovering distillates can be realized.
We provide reactors of various specifications, ranging from 500mL to 200L.
The product can be matched with water circulation vacuum pumps, low temperature circulators, high temperature circulators and refrigeration and heating circulation devices to form a system device.
It can be widely used in experiments and production needs in petroleum, chemical, rubber, pesticides, dyes, biopharmaceuticals, food, etc.
Characteristics:
1.PTFE seals have good corrosion resistance;
2.Glass parts are designed with high borosilicate 3.3 and have stable chemical properties;
3.Frequency control and adjustable stirring speed;
4.Stainless steel stirring rod, externally wrapped with PTFE, has good corrosion resistance;
5.The reflux condensation area is large and the condensation effect is good;
6.The overall frame is made of stainless steel,with footwheel,easy to move.
Constructure
Specification
| Model | AGRL-10L | AGRL-20L | AGRL-30L | AGRL-50L | AGRL-100L | AGRL-200L | |
| Vessel volume(L) | 10 | 20 | 30 | 50 | 100 | 200 | |
| Jacket volume(L) | 5 | 6 | 10 | 13 | 30 | 60 | |
| Condenser heat exchange area(m2) | 0.2 | 0.3 | 0.4 | 0.6 | |||
| Constant pressure funnel volume(L) | 1 | 2 | |||||
| Recycling bottle volume(L) | 0.5 | 1 | |||||
| Temperature (ºC) | -80~200 | ||||||
| Ultra vacuum(Mpa) | -0.098 | ||||||
| Temperature limit difference inside and outside of vessel(ºC) | ≤80 | ||||||
| Pressure designed for vessel(Mpa) | -0.1~0.0 | ||||||
| Motor stirring power(W) | 120 | 200 | 370 | ||||
| Speed adjust method | Stepless speed regulation | ||||||
| Rotation speed(rpm) | 0~450 | ||||||
| Agitator | Stainless steel material,with PTFE layer,Paddle stirring blade | ||||||
| Power supply | 220~240V,50Hz;110V/60Hz | ||||||
| Size(mm) | 780*610*2050 | 800*620*2150 | 800*630*2200 | 830*650*2300 | 950*780*2800 | 1060*1060*3050 | |
Equipments work for Glass reactor
Packaging & Shipping
Factory & Workshop
FAQ
Q : What products can you offer?
A : We are a one-stop laboratory instrument supplier that can provide customers with products and solutions according to their needs.
Q : How long is your usual delivery time?
A : Our products are usually shipped out 5-7 days after receiving payment.
Q : What transportation methods do you support?
A : We support express delivery (DHL/FEDEX/UPS/TNT), trucks, trains, planes, and ships.
Q : What trade methods can you accept?
A : We support EXW, FCA, FOB, CFR, CPT etc
