EPS Hot Melting Recycling Machine, Crush Melt for EPS/XPS/EPE Foam Material Processing

Product Description

The EPS Melting Machine can efficiently crush and thermally process EPS, XPS, EPE, EPO, and other foam materials. It operates without the need for a heater at the chamber end, setting it apart from conventional melting machines.
Benefits of 'Friction Heat Generation
1) Virtually no preheating time required; materials can be fed immediately after the machine is activated. Traditional lump machines with heaters require approximately 20 minutes to heat the chamber.
2) Produces minimal smoke, ensuring a cleaner working environment.
3) Produces almost no odor, maintaining a more pleasant workspace.
4) Optional heater integration for processing wet foam materials, as the heater can elevate the chamber's internal temperature.
The EPS Crushing and Melting Machine features dual crushing shafts within the hopper, optimizing its crushing efficiency.
An optional conveyor system is available for material feeding.
Equipped with temperature and frequency control systems within the control box.
Includes a robust hard teeth reducer and a durable copper motor within the hot melt machine.
The chamber boasts a diameter of 245mm, enhancing material processing capacity. Machine Application
Machine Advantage
Machine Parameter

Hopper Size	Capacity	Chamber Dia.	Shredding Shafts Qty	Motor Power	Machine Size
800*800mm	200kg/h	245mm	2 pcs	18.5kg	1600*1500*800
