Xgma 24.2 Tons Hydraulic Crawler Excavator Xg825EL Remote Control Mining Excavator Loader

Product Description

Product Parameters

Type	unit (of measure)	XG825EL
Working mass	T	24.2
Bucket capacity(SAE)	m3	1.2
Engine model		CUMMINS QSB7
Power	kw/r/min	140/2000
Volume of fuel tank	L	350
Travel speed (High/Low)	km/h	5.69/3.86
Swing speed	r/min	12.82
Gradeability	°	35
Digging force of bucket	KN	159
Digging force of stick	KN	115
Specific pressure of ground contact	Kpa	48.6
Traction		219
Maximum flow	L/min	226*2
Working pressure	Mpa	34.3
Volume of hydraulic fluid tank	L	230
Overall length	mm	9740
Overall Width	mm	2980
Overall height(tope of boom)	mm	3190
Overall height(tope of cab)	mm	3120
Gap from counterweight to ground	mm	1065
Min ground clearance	mm	442
Tail swing radius	mm	2810
Length of track on ground	mm	3640
Track length	mm	4450
Gauge	mm	2380
Width of track	mm	2980
Width of track shoe	mm	600
Width of turning table	mm	2700
Max. digging height	mm	9310
Max. dumping height	mm	6438
Max. digging depth	mm	6875
Max. digging distance	mm	10170
Max. digging distance at plane	mm	9990
Min. swing radius	mm	3975
Max height at min swing radius	mm	7775
Distance from center of swing to rear end	mm	2810
Y-Thickness of track grouses	mm	26
Height of counterweight	mm	2120
Ground Contact length (in transportation)	mm	5165
Length of stick	mm	3050
	mm	5850

Detailed Photos
Company Profile
Partners&Cases
Packaging & Shipping
To serve customers in different regions, we have a variety of sound and safe logistics solutions to ensure that every order can be safely and efficiently delivered to the destination.
After Sales Service
We have the professional after service team guarantee customers get the full service for spare parts, technology and maintenance, all the hardworking in order to customers get the continuous and better development.
FAQ
Q1: What are the delivery times for vehicle exportation?
A1: If the vehicle is in stock, we will deliver the vehicle within 5-10 days. If not, we will produce the vehicle, arrange the shipping, and complete delivery within 25-35 days. For other special vehicles, it might take more time to refurbish them according to your requirements.
Q2: What are the modes of transportation?
A2: Normally, Russia and Central Asia are suitable for truck and train transportation, and other regions such as the Middle East, Africa, and South America are suitable for sea transportation.
Q3: What are the delivery terms?
A3: EXW, FOB, CIP, CIF.
Q4: What are the payment terms?
A4: You firstly need to pay a 30% deposit after signing the trade contract with us, and then you need to pay the remaining 70% balance before the vehicle is shipped.
Q5: What are the payment terms and options?
A5: TT, L/C.
Q6: Do you provide after-sales support?
A6: Yes,we have a professional after-sales service team, who can provide technology support for you. Our team in China can purchase spare parts for you with competitive price and ship them to your location. (We ensure that every vehicle we send out is of excellent quality and will not require repairs under normal circumstances.)
