Huadai Solid Silicone Rubber for Extrusion Wire Tubes Making Htv

Product Description

Huadai Solid Silicone Rubber for Extrusion Wire Tubes Making HTV
Huadai solid silicone rubber is a 10 years experience manufacturer located in Dongguan city China.
we have competitve price and very stable quality.
The series of hardness range is 30-90 SHA, has the characteristics of high transparency, good workability,easy stripping,etc. Products are generally applicable to all kinds of silicone household products,sundries,swimming cap,tableware and baby products,etc. Product Features:
High transparentcy; Excellent processing property;
Esay to demould;
Pass the certification of ROHS,REACH .

HD-1X0 Series
Product Type		General Molding Products
Product Model		HD-130	HD-140	HD-150	HD-160	HD-170	HD-180
Appearance		Translucent	Translucent	Translucent	Translucent	Translucent	Translucent
Williams Plasticity		120-140	130-150	160-180	190-210	220-240
Density (g/cm3,25ºC)		1.10-1.15	1.11-1.16	1.13-1.17	1.15-1.18	1.19-1.22	1.22-1.25
Vulcanization	Type	C-6	C-6	C-6	C-6	C-6	C-6
	Dosage (%)	1%	1%	1%	1%	1%	1%
After Vulcanization	Linear Shrinkage (%)	3.3±0.2	3.3±0.2	3.3±0.2	3.3±0.2	3.3±0.2	3.3±0.2
	Hardness (Shore A)	30±2	40±2	50±2	60±2	70±2	80±2
	Tensile strength (MPa)	≥7	≥8	≥8	≥7	≥7.5
	Elongation (%)	≥600	≥500	≥400	≥400	≥200
	Tear Strength (KN/m)	≥15	≥15	≥18	≥20	≥13
	Compression Set (%)	≤6	≤5	≤6	≤6	≤7
	Temperature Tolerance (200ºC/4h)	No Obvious Yellowing
Above data for reference only, factory inspection report shall prevail for latest testing standard and data.

Certifications Product Advantages 1.High Temperature: Silicone rubber applicable temperature from -40°C to 230°C, it can be used in microwave and oven. 2.Easy to Clean: Silicone rubber finished products just need water to do cleaning. 3.Long Life: Silicone rubber stable in chemical properties. 4.Soft and Comfortable: Benefit from silicone rubber softness, mould products comfortable touch, extremel flexible and not deformed. 5.Environmentally Friendly: Silicone rubber does not produce and toxic or hazardous substances from raw materials to finished products. 6.Electrical Insulation Performance: Silicone rubber have high resistivity. 7.Low Temperature Resistance: Silicone rubber in - 60°C to - 70°C still have good elasticity. Our company has also developed some silicone rubber that can withstand lower temperature for mulations. 8.Conductivity: Silicone rubber have good conductivity when add conductive material (such as silicon dioxide). 9.Weather Fastness: Silicone rubber is not offected by ozone, long time in Ultraviolet light and other climatic conditions, its physical properties are only slight changed. 10.Thermal Conductivity: Silicone rubber have good thermal conductivity when add some raw materials. 11.Radiation Resistance: Radiation resistance of phenyl-containing silicone rubber is greatly improved. Packing & Delivery 1 PC of HTV silicone rubber is 10KGS, and in a blue plastic packaging. 2 PC of 10KG HTV silicone rubber put in a carton. 50 cartons for a pallet Loading for shipment
Technical Instrument Our Service 1.Pre-sale: Our technical team will according to customer need to recommend the most suitable product for customer. 2.Technology R & D: If customer products are special, we can develop new products for our customers. 3.Quality Control: At the time of production, our company's quality inspection team will take several samples to conduct the whole process of quality inspection, and the production workers will strictly follow the requirements to produce. 4.After-sale: Our sales team will follow up to the customer's use of the product.If there are any problems, our technical team will try our best to provide solutions. 5.OEM support: Strong technical team support, our company has core technology for R&D, which can be carried out for customers OEM. Our Company Dongguan Huadai Silicone Co.,Ltd it is a high-tech enterprise specializing in the R&D, production and operation of silicone products.
The company longevity "covers the area of 26700 square meters and the building area of 30,000 square meters.Now, our company equip with the silicone rubber automatic production lines and various advanced silicone rubber production equipment , none but Huadai own the full auto-lines for the manufacture of silicone rubber in China.Its annual production capacity is about 90000 tons.
