Plug Surge Protector, Voltage Protector Socket Refrigerator Voltage Relays

Product Description

SINGLE-PHASE VOLTAGE MONITORING RELAYSOutlet-Voltage relay 2166 EU is designed to protect the domestic appliances (equipment) rated for power up to 3.6 kW (refrigerators, air conditioners, washing machines, television and audio equipment, etc.) from inadmissible voltage oscillations in the network and the consequences of neutral breakdown.
Outlet-Voltage Relay 2166 EU: Ensures shutdown of the protected equipment if voltage value in the network is beyond the limits set by the User (on restoration of network parameters, automatic reclosing will take place (hereinafter referred to as ARC); Provides indication of voltage value in the network and presence of voltage in the outlet of the device.
Single-Phase Voltage Relays
A single-phase voltage relay is a device intended for effective voltage automatic control and such equipment as home appliances and other devices in homes and offices protection (disconnection). This process is required when the voltage deviates from the set values.
Voltage relay (single-phase) only performs the function of protection against voltage drops. When the supply network is worn out, single-phase loads distribution is not properly performed (due to the maintenance personnel low skills), as well as in case of "zero" disconnection or any other electricity network emergency, the device performs "consumer protection" by de-energizing in order to prevent the equipment failure.
Features:
+ Plug-in installation, small size, easy to install, no screw fixing
+ Suitable in the circuit of line voltage 220v ac, 60Hz or 50Hz under rated power
+ Protector cut off power supply at once for exceeding the over voltage, and recover automatically 30s later after circuit back to normal
+ Automatic recovery delay time 30s: prevent additional damage to the electrical appliances due to frequently switch on and off caused by the unstable voltage
+ Protector also cut off power supply at once for voltage sag
+ Working status indicator: green for working (on), red for protection (off), yellow for time delaying (wait)
+ 750ºC high temperature resistant and flame retardant enclose
+ 0.7mm thick beryllium bronze
+ Domestic top brand high quality relay
+ Chip in Taiwan and USA imported original brand
Applications:
+Fridges
+Freezers
+Cooler
+Pumps
+All motor drived equipments
+Protect the home appliances against the damage of low voltage, Surge, Spike, etc.
Specifications:

Name	Voltage relay or TV DVD Fridge Guard
Norminal voltage	220V AC
Frequency	50Hz/60Hz
Current Rating	10A/13A/15A/16A
Under-voltage disconnect	180VAC
High-voltage disconnect	260VAC
Spike Protection	160J
Wait time	30 seconds or 3 minutes adjustable
Main surge/spike response time	Less than 10ns
Mains max Spike Surge	6.5KA
Warranty	2 years
