4lz-5.0s Double Threshing Combine Harvester

Product Description

Product Description
Introducing the 4LZ-5.0S Combine Harvester by Deyang City Jinxing Agricultural Machinery Manufacturing Co., Ltd. This top-of-the-line harvesting machine is designed to revolutionize your agricultural operations. With its advanced features and cutting-edge technology, it guarantees efficient harvesting of rice, corn, wheat, soybean, and rape seeds.
The 4LZ-5.0S Combine Harvester is equipped with a double threshing system, ensuring exceptional performance and superior grain separation. Its self-propelled crawler design allows for easy maneuverability across different terrains, providing convenience and flexibility in your farming activities.
Designed specifically for modern farmers, this multi-purpose harvester has a high output capacity and efficient operation, significantly enhancing productivity and saving valuable time and resources. Its versatility makes it a reliable and durable choice for your farm, maximizing crop yield and streamlining your farming process.
Invest in the 4LZ-5.0S Combine Harvester and experience the power and efficiency of this state-of-the-art agricultural machinery. Order now and take your farming operations to new heights!
Multifuntional for Different Crops

Enhanced high chassis, integrally-formed steel wheels, wearing materials for conveying parts.
Wider header, bigger thresher, bigger grain tank, powerful diesel engine.
Suitable for lodging crops, super tall crops, high output crops, or deep mud field and large field.

Product Parameters

Product Model			4LZ-5.0S Combine Harvester
Overall Dimension Length×Width×Heights ( mm ):			4780×2490×2910
Weight (kg)			3100
Productivity of Operating Hours(hm²/h):			0.27~0.96
Engine	Engine Model		4D35ZT32/1004
	Rated Power ( kw/hp )		73.5KW/100HP, 65KW/88HP
	Engine Type		Water-Cooled, 4-Cylinder, DI-Injection, Vertical Turbocharged Diesel.
	Rated Rotation Speed (r/min)		2400
Traveling System	Type of Gearbox:		HST X (3F, 3R) Hydraulic type + HST(3F, 3R)
	Rubber Track(mm):		500 x 90 x 51, 550 x 90 x 51
	Gauge		1150
	Minimum Ground Clearance (mm)		310
Cutting header	Height Adjustment		Hydaulics.
	Cutting Width ( mm )		2200, 2000
	Header auger type		Telescopic Screw Conveying
	Pickup Reel		D944mm; Qty 5 Eccentric Tooth(off-centre)
Threshing System	Threshing System		Spiked Tooth Axial Flow
	Threshing Cylinder Quantity		2
	Cylinder Diameter×Length ( mm )		Main Cylinder φ540 x 1285, Assistant Cylinder φ540 x 650
	Cleaning Mechanism Type		Air and Screen Cleaning, Vibrating Sieve adjustable
Grain Storing	Automatic Unloading		1300L 360° / 90° Big Grain Tank Capacity 1300L with 360° / 90°Unloading Auger
	Manual Operation		450L Small Tank Capacity 450L by Manpower
Information is based on published information at the time of publication, any change without notice.

We wre open to customize product and soulutions for your local field. Integrated after-sales management system. International mechanism of modern enterprise system. Over 70% sales is oversea market.
