The Best Price Ring Focal Parabolic Antenna

Product Description

Products Description A ring focal antenna is commonly referred to as a parabolic focal axis offset axisymmetric dual mirror antenna. Given that the focal trajectory of this antenna is a circular ring, it is called a ring focal antenna; The ring focal antenna has a unique position in satellite communication earth station antennas, especially in small and medium-sized satellite communication earth stations. Using this antenna can overcome the disadvantage of the secondary obstruction caused by the corrugated horn as the primary feed source being greater than that caused by the secondary mirror. The ring focal antenna developed by Wenfeng Communication is widely used in the field of satellite communication, with aperture sizes ranging from 1 meter to 4.6 meters. specifica

Model Type frequency range(GHz) Antenna aperture (mm) Working bandwidth gain(dB) gain(dB) Sidelobe level standing-wave ratio standing-wave ratio E-Plane H-Plane EF-120HRA500I 10-15 500 10% ≥31.5 3° -14 -14 ≤1.5 FBP120/N-50K EF-120HRA600P1 10-15 600 10% ≥33 2.6° -14 -14 ≤1.5 FBP120/N-50K EF-120HRA800I 10-15 800 10% ≥35.5 2° -14 -14 ≤1.5 FBP120/N-50K EF-120HRA900I 10-15 900 10% ≥36.8 1.8° -14 -14 ≤1.5 FBP120/N-50K EF-120HRA1800I 10-15 1800 10% ≥42.8 0.85° -14 -14 ≤1.5 FBP120/N-50K EF-140HRA1800I 12-18 1800 10% ≥44.5 0.7° -14 -14 ≤1.5 FBP140/SMA-50K EF-84HRA2400I 6.57-10 2400 10% ≥39 0.95° -14 -14 ≤1.5 FBP84/N-50K EF-120HRA500I 10-15 500 10% ≥31.5 3° -14 -14 ≤1.5 FBP120/N-50K EF-120HRA600P1 10-15 600 10% ≥33 2.6° -14 -14 ≤1.5 FBP120/N-50K EF-120HRA800I 10-15 800 10% ≥35.5 2° -14 -14 ≤1.5 FBP120/N-50K EF-120HRA900I 10-15 900 10% ≥36.8 1.8° -14 -14 ≤1.5 FBP120/N-50K EF-120HRA1800I 10-15 1800 10% ≥42.8 0.85° -14 -14 ≤1.5 FBP120/N-50K EF-140HRA1800I 12-18 1800 10% ≥44.5 0.7° -14 -14 ≤1.5 FBP140/SMA-50K EF-84HRA2400I 6.57-10 2400 10% ≥39 0.95° -14 -14 ≤1.5 FBP84/N-50K

Product picture
Product Description Standard Gain Horn Antenna A horn antenna can be viewed as a gradually opening waveguide. The function of the horn is to generate a uniform phase wavefront over the larger aperture of the waveguide, resulting in higher directivity. A standard gain horn antenna is a horn antenna whose gain is scaled to the frequency characteristics. The bandwidth of the horn antenna is determined by the operating frequency range of the main mode in the waveguide connected to it. The operating frequency of the rectangular waveguide is determined by the operating frequency range of the main mode TE10 mode, and the gain is mainly from 10 dB to 25 dB. Applications of Standard Gain Horn Antenna 1.Automotive Antenna Test Solutions Cars are becoming 'antenna farms' with as many as 10 to 80 antennas mounted on them with the addition of new consumer-oriented services. Military vehicles and industrial fleet vehicles also continually add additional antennas for specialized communications, movement coordination and data gathering. While conventional antenna testing techniques are not effective due to new spatial coverage and frequency requirements, NSI-MI has developed solutions for automotive antenna testing applications. Our systems allow for the characterization of antennas for cell phones, GPS, satellite radio, collision avoidance, automated tolling, traffic monitoring, personal area networking, AM/FM radio, and more. NSI-MI has developed spherical near-field measurement systems for
vehicular antenna testing applications in both indoor and outdoor environments.
2.General Antenna Testing
Our test and measurement facilities coupled with our highly experienced staff are available to support your testing requirements. Whether you need to test in the near-field, far-field or a compact range, NSI-MI can provide accurate and fast results.
3.Radar Cross Section
We provide state-of-the-art radar cross section measurement systems suitable for measuring small-scale test articles and/or full-scale vehicles depending on customer requirements.
4.Radome Testing
The military and commercial aircraft carry a vast array of antennas for specialized and vital functions. Communications, navigation, weather and fire control antennas must perform as specified to meet safety and mission requirements. Radomes must conceal and protect antennas without interfering with or degrading transmit/receive capabilities.
5.Satellite Antenna Testing
RF testing of flight hardware poses challenges that are unique to the space industry and antennas specifically, are often delicate and gravitationally sensitive. Minimizing or even avoiding motion of these antennas during testing is highly desirable for two reasons: Firstly, it minimizes risk to the antennas. Secondly, the standard gain horn antenna can be deployed with respect to a fixed gravity vector.
6.Wireles
Wireless networks rely on antennas and our products allow for the reliable characterization of these antennas. We offer test systems that are suitable for evaluation of electrically small handset or other UE antennas, as well as electrically large base station antennas. Packaging & Shipping
Company Profile
Xi'an EFine Telecom Technology CO.,Ltd (EFine Telecom hereinafter) is a leading microwave waveguide components, assemblies and antenna systems manufacturer in China. Established in 2011, EFine Telecom is continually growing to meet customer's needs. Our highly trained design engineers and manufacturing personnel can handle both standard and custom products to meet your needs. Our in house design, manufacturing, inspection and quality control capabilities allow fast response to customer requirements. Our standard delivery time is only half of the average western supplier's standard delivery time. Our microwave measurement capability up to 60GHz makes us the best choice for the design and manufacturing of your components. We implement TQM (Total Quality System) and SOP (Standard Operation Procedure) with ISO 9001:2017 certification, which assures WinFine Telecom's strong commitment to quality standards and customer satisfaction. We are confident we offer well-engineered, high quality products at globally competitive prices. Our mission is to satisfy our customers by providing timely and cost effective solutions without compromising quality, performance and delivery. Manufacturing Technique
