4080ahd Saddle Type High Precision Heavy Surface Grinding Machine

Product Description

Product Description
4080AHR Machine Features:
1. Crafted with premium-quality, high-grade cast iron, the machine's main castings undergo meticulous annealing and shock aging treatments. This process effectively alleviates internal stress, enhancing the stability and greatly reducing the risk of deformation.
2. Engineered for superior work efficiency, our machine boasts a robust, thick, and stable fuselage, perfectly satisfying the rigorous demands of heavy-duty cutting and precise grinding.
3. The guide rail is fortified with a high-quality wear-resistant adhesive. Paired with expertly crafted precision shovel flowers, this ensures exceptional accuracy and enduring durability.
4. Spindle arm end swing precision is maintained at an impressive 0.003mm.
5. Equipped with a precision ball screw, the machine offers operations that are lighter, more accurate, and long-lasting.
6. Our independently designed hydraulic system components operate with minimal vibration and noise, ensuring a serene and efficient environment.
7. Designed with an intelligently configured cable pipeline, offering resilience and reliability.
8. The lubricating oil pathway comes with a self-test feature, fault alarm, and automatic cycling, all supported by a pressure sensor to ensure unfailing guide rail lubrication.
Product Parameters
PCA 4080 Contains: 4080AH/4080AHR/4080AHD/4080NC/4080CNC

Parameter list	parameter	unit	PCA4080
ability	Table area(x*y)	mm	800*400
	Maximum left and right movement(x)	mm	950
	Maximum amount of movement before and after(Y)	mm	460
	Maximum distance from table to spindle center	mm	510
	Maximum weight of table	kg	600
workbench	Table T-slot	mm×N	14*3
	Table speed	m/min	5-25
front and rear structure	Front and rear hand wheel feed (1 grid /1 turn)	mm	0.02/5
	Automatic feed front and rear	mm	0.1-8
	Dart back and forth(50HZ/60HZ)	mm/min	990/1190
Grinding wheel	Grinding wheel size	mm	350*40*127
	Grinding wheel speed(50HZ/60HZ)	R.P.M	1450/1740
Up and down structure	Upper and lower hand wheel feed (1 grid /1 turn)	mm	0.005/1
	Up and down fast moving speed	mm/min	230
motor	Spindle motor	HXP	10*4
	Up and down drive motor	W	150
	Hydraulic motor	HXP	3*6
	Flush motor	W	90
	Front and rear drive motor	W	80
dimension	Overall dimensions of the machine (L × W × H)	mm	2580×2270×1900
	Weight (approx)	kg	≈2600

Standard Configuration
1. Includes a magnetic sucker measuring 400 x 800mm for robust hold.
2. Comes with a comprehensive cooling water tank system.
3. Supplied with a practical set of flange and flange wrench.
4. Features a set of horizontal adjusting screws and foot pads for precise leveling.
5. Includes a hydraulic system (hydraulic oil not included).
6. Fitted with a standard grinding wheel of size 350*40*127mm (46#).
7. A complete set of wheel removal screw, pen holder, and pen is included.
8. Comes with one adjustable disk controller for enhanced operability.
9. Includes a set of grinding wheel balance frame and balance rod for optimal stability.
10. Equipped with a set of up and down quick function capabilities.
11. Toolbox, standard tools, and an instruction manual set are all provided for your convenience.
Remark
AH Features left and right hydraulic movement, front and back step, with manual up and down control.
AHR Offers left and right hydraulic movement, front and back step, with a fast lift for up and down.
AHD Provides left and right hydraulic movement, front and rear step, with servo automatic control for up and down.
NC Incorporates left and right hydraulic, front and rear servo, and up and down servo automatic control for seamless operation.
CNC Boasts X, Y, Z, three-axis CNC, pushing precision to the next level.
Detailed Photos
Our Advantages
Certifications
FAQ
1.What is the MOQ for your production?
A.The MOQ depends on your requirements for color, logo and so on.For some normal items, we have in stock, the MOQ is 1 set.
2.How to control the quality of the products?
A.We have always placed great emphasis on the quality level is maintained.Moreover,the principle we always maintain is "to provide customers better quality, better price,and better service".
3.What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Machine, Lathe Machine , Milling Machine,Grinding Machine ,Vertical Machining Center ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine and so on .
4. What is your trade terms?
A :Ex-works FOB, CFR and CIF all acceptable.
5.What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
6.What CNC system do you use?
A:FANUC, SIEMENS, MITSUBISHI, SYNTEC, HCN .It depends on your choice.
7.How can I choose the most suitable machines?
A:Send us the products drawings and applications ,we will choose the most suitable machines for you.
8.what kind of package do you offer?
A.Normally in plywood case, to make sure all goods in good condition. Customized package can be acceptable.
9.Can your plant do OEM?
A:Yes it is no problem. We can do OEM and ODM for any customers.
10.How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for mac.
