X6330 Horizontal Vertical Milling Machine
| US$2,000.00-8,000.00 | 1 SET (MOQ) |
Basic Info.
Model NO.
X6330
Object
Tool
Structure
Gantry
Milling Cutter Type
Cylindrical Milling Cutter
Milling Cutter Structure
Overall Welding Tooth
Controlling Mode
CNC
Automatic Grade
Automatic
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Transport Package
Wooden Case
Trademark
SJMC
Origin
China
HS Code
8459409000
Production Capacity
5 Units / Month
Product Description
X6330 horizontal vertical milling machine with accsesories digital readoutMain feature
1. Robust construction and heavy duty design.
2. The machine body is made of Meehanite cast iron
3. The milling head is imported from Taiwan.
4. The milling head can swing 90° right and left side,45° front and back side.
5. The ram can swing 180° horizontally.
6. The working table and guide rail are heating treated and precision grinding.
7. DRO and dividing head are for option.
| Model | X6323 | X6325T | X6330 | X6332 |
| Longitudinal travel(X) | 762mm | 800/900mm | 780mm | 1100mm |
| Later travel(Y) | 305mm | 400mm | 425mm | 425mm |
| Vertical travel(Z) | 407mm | 405mm | 450mm | 450mm |
| Table size (L×W) | 230×1065/1246mm | 254×1270/1370mm | 305×1370mm | 320×1670mm |
| Spindle Lifting Travel | 127mm | 127mm | 132mm | 132mm |
| Spindle taper | R8/NT30 | R8/NT30 | NT40 | NT40 |
| Spindle motor | 3HP | 3HP | 5HP | 5HP |
| Spindle center to column | 172-477mm | 190-685mm | 170-756mm | 170-756mm |
| Spindle nose to table | 0-458mm | 0-428mm | 0-580mm | 0-580mm |
| Swivel of the spindle head (from after to before) | ±45degree | ±45degree | ±45degree | ±45degree |
| Swivel of the spindle head (from left to right) | ±90degree | ±90degree | ±90degree | ±90degree |
| Arm stroke | 356mm | 550mm | 570mm | 590mm |
| Spindle speeds | 16segment | 16segment | 10segment | 10segment |
| 50Hz: 60-4500rpm 60Hz: 80-5440rpm | 50Hz: 60-4500rpm 60Hz: 80-5440rpm | 70-3600rpm | 70-3600rpm | |
| Form of X shaft orbit | Dovetail | Dovetail | Dovetail | Dovetail |
| Form of Y shaft orbit | Dovetail | Dovetail | Souare Rail | Souare Rail |
| Form of Z shaft orbit | Dovetail | Dovetail | Souare Rail | Souare Rail |
| Z axis drive | | | Automatic | Automatic |
| Lubrication system | Manual | Manual | Automatic | Automatic |
| Machine Dimensions (L×W×H) | 160×173×208cm | 160×173×220cm | 179×190×242cm | 179×190×272cm |
| Machine weight | 950kg | 1200kg | 1600kg | 1700kg |
