High Efficiency One Stop Solution Chromatograph Machine HPLC Systems High Performance Liquid HPLC Chromatography

Product Description

Product Description
Chromatography is used to separate proteins, nucleic acids, or small molecules in complex mixtures. Liquid chromatography (LC) separates molecules in a liquid mobile phase using a solid stationary phase. Weshine invented that VS-HPLC Liquid chromatography can be used for analytical or preparative applications. Product Name: HPLC Liquid Chromatography
Standard: DL/T 1355-2014
Liquid flow control:High Pressure Constant Flow Infusion Pump
Detector:UV-Vis Variable Wavelength Detector
Sampler:Liquid Control Autosampler 200samples
One Column:C18 4.6*250mm, 5um
Flow Setting Range:0.001~9.999ml/min
Flow Stability:Less 0.2% RSD
Maximum Infusion Pressure:0~9999Psi
Flow Infution Pump:One/Two-Sets High Pressure
Constant Flow Infution Pump

Model		VS-HPLCI980	VS-HPLCG980	VS-HPLCQL980
Pump	Type	Isocratic Pump	Gradient Pump	Quarternary Low Pressure Pump
	Flow Rate Range	0.001-10.000mL/min, in 0.001mL increments
	Flow Accuracy	≤±0.2% (1.00ml/min, H2O,R.T.,8.5MPa)
	Flow Precision	RSD≤0.06% (1.00ml/min, H2O,R.T.,8.5MPa)
	Maximum Pressure	63MPa
	Pressure accuracy	≤±3.0%
	Pressure pulsation	≤0.1MPa
	Composition rang	/	0-100%	0-100%
	Composition precision	/	≤0.2%RSD	≤0.3%RSD
UV/VIS Detector	Wavelength Range	190-800nm
	Wavelength Repeatability	≤0.1nm
	Wavelength Accuracy	≤±1.0nm
	Band Width	6nm
	Response Time	0.0s-5s
	Baseline Noise	≤±0.25×10-5AU(empty cell, 254nm, 1.0s)
	Drift	≤0.5×10-4AU/h(empty cell, 254nm, 60min)
	Path length	10 mm(analytical cell)
	Light Source	Deuterium Lamp and Tungsten Lamp
Data-processing Workstation		Sequence tables for any set of samples Internal and external standard calculation methods Automatically displays, prints, exports and starts other programs after the completion of a measurement.
System Manager		Integrated A/D converters		Integrated A/D converters Integrated vacuum degasser, 4 channel
Power Supply		AC110/220V±10%, 50/60Hz
Optional Accessory		Column Oven, Autosampler, Degasser, Diode Array Detector, Refractive Index Detector, Evaporative Light Scattering Detector, Fluorescence Detector

FEATURES1. High pressure constant flow pump with parallel pump heads and optimized 5mm stroke of plunger rod ensuring perfect pump performance
2.The higher level of integration with binary or quaternary pumps integrated into one set of module
3.Specially designed column oven for GPC, which represents greater capacity of three columns, max ID10×250mm
4.Adoption of advanced UDP communication protocol that is fast, stable and can be used for instrument remote control
5.The HPLC system being more integrated and intelligent
