Product Description

Pile Driver Mini Hand Held Pile Driving Hammer ZSS1000 yantai factrory


Wide range of functions:
Our Excavator Mounted Vibratory Hammers are used to drive or extractvarious steel profiles; sheet piles,
H-beams, and l-beams and the biggertypes, fitted with double clamps, casings and tubular piles, can be driven.The Vibro Hammers have a very narrow throat width that allows you tocarry out staggered sheet piling, and with a wide range of VibratoryHammers and clamps, we have the solution for all types of steel, woodand concrete piles and all different soil conditions. suitable for any soil layer and can be used for piling, pulling out piles and underwater piling, and can per-form pile racking and suspension operations.The upper body allows 360 degree auto rotation by foot pedal or joystick

Product Parameters

MODEL	UNIT	ZSS250	ZSS350	ZSS500	ZSS600	ZSS650	ZSS800	ZSS1000	ZSS1100
Vibration Frequency	rpm	3200	3000	2800	2800	2700	2400	2300	2300
Eccentricity Moment Torque	nm	22	36	52	70	83.5	126	175	180
Rated Excitation Force	kn	250	360	450	600	650	800	1050	1100
Hydraulic System Pressure	mpa	32	32	32	32	32	32	32	32
Hydraulic System Flow Rating	lpm	105	250	240	315	310	310	380	380
Maxinum Pile Length	m	6-9	6-9	6-15	6-18	6-18	6-22	6-30	6-36
The Auxiliary Arm Weight	kg	700	800	800	900	900	1000	1000	1000
Total Weight	kg	1250	1750	2750	3200	3200	3600	3300	4200
Suitable Excavator	ton	15-20	18-25	27-37	36-50	42-50	50-70	70-90	70-90

Our Advantages
1. Hydraulic rotary motor and gear hidden, can effectively avoid oil and collision, gear replacement is convenient, with tight, stable and durable.
2.The box adopts open structure to ensure the balance of pressure in the box and stable heat discharge.
3. High performance shock-absorbing rubber block, stable quality, long life.
4. Original imported hydraulic motor, stable efficiency, stable quality.
5. The nozzle cylinder has strong thrust and maintains pressure, which is stable and reliable to ensure that the pile is not loose and the construction is safer.
6. The nozzle is made of imported wear-resistant plate with stable performance and long service life.
Product Description
Excavator Mounted Vibratory Hammer Excavator mounted vibratory hammer is used withexcavator and installed on the first end of excavator.It's equipped with rotation gear box which can rotate360 degree, with left and right rotating 180 degreeeach.And also Elastomer, which can reduce shock
Side Grip Vibratory Hammer Side grip vibro hammer can grip the pilefrom both the pile top and pile side, nolifting height limit of excavator boom liketop grip model hammer. lf the pile lengthis 12m, excavator is 25tons, it can alsodo the piling job, no need to change theexcavator boom. lt is small, very conven-ient for installing and transportation.
Factory display
Certifications

Our service
1. We have our own factory, easy to control every step of production to ensure the quality.
2. We cherish our fame and use high quality parts. High quality parts make high quality products.
3. We can do OEM and customized products based on our professional engineers team.
4. Efficent and prompt after-sale service
5. We can hit different types of piles.
6. Our vibro hammer is more powerful than other regular hammers, easier to drive the piles into earth.
Company Profile
Yantai Zhuoxin Machinery Technology Company limited is a professional enterprise committed toindependent excavator attachment researching, developing and marketing. As for now, we has built reliable relationship with clients more than 20 countries. Such asThe United states, Russia, Australia, New Zealand, Japan, South Korea, Malaysia, lsrael, indiaetc. All product quality is strictly under control from processing to delivery. we main products include Quick hitch coupler, wood grapple, stone grapple.demolition grapple, multi-function grapple, orange peel grapple, breaker, hydraulic auger, hydraulic pulverizer, scrap shear, crusher, bucket, plate compactor, riper, rake and dozens ofexcavator front-end device products. These reliable attachments are widely used in constructionwork, earth work, demolition work and mining industries both in china and overseas.
FAQ
Q1. Are you a manufacturer?Yes,We have our own independent factory, you can get the most favorable factory price directlyQ2. How many days for the delivery time ?It is about 1-7 working days after the order confirmation.Q3. What kind of payments you accept?Now we accept T/T, L/C or Western Union, other terms also could be negotiated, Recommended Trade Assurance to guarantee buyer's property.Q4. Are you able to manufacturing products according to customer's design?Sure, we have made many special orders from oversea for 10 years since 2010. So we have enough ability to deal with any cases. OEM certificate is available to provided.Q5. What's your advantages in the machinery manufacturing industry?Fast delivery time, High quality products, Best customer service, Adopting the latest production technology.Q6. Which countries have you been exported recently?Canada, Australia, Peru, Egypt, Brazil, Mexico, South Africa, etc.Q7. Are you sure that your product will fit my excavator?We have different brand hydraulic breakers. Show me your model number, and we can give you best match products.Q8. How about the packing of the goods?Standard export package, wood cases, or as customers' demands.
