US$9,850.00-10,650.00
|
4 Pieces
(MOQ)
|
Basic Info.
Suitable for
Tourist Area
Certification
CE, EEC, ISO
Color
All Color Available
Engine
600cc Model, 1100cc Available
Transmission
Automatic and Manual Transmission Both Available
Lead Time
30 Days After The Receipt of Deposit
Transport Package
Steel Frames Packaged
Specification
Gasoline engine power
Production Capacity
50 Units/Month
Packaging & Delivery
Package Size
320.00cm * 150.00cm * 150.00cm
Package Gross Weight
480.000kg
Product Description
Company
Product Parameters 600CC gasoline model mini moke
Engine |
Type | 600cc.Water-cooled. 8 valves. L2. |
Bore*Stroke(mm) | 72*72 |
Compression Ratio | 9.8 |
Max.Power(kw/rpm) | 25/5500 |
Max.Torque(Nm/rpm) | 52/3000-3500 |
Fuel Supply System | MPFI |
Max.Speed km/h | 85 |
Starting | Electric |
Min stable speed (rpm) | 1000±50 |
Min fuel consumption(g/kw.h) | 265 |
Ignition type | Inductance discharge type |
Spark plug model | LDK7RTC |
Distribution type | DOHC |
Lubrication type | Pressure spray lubrication |
Lubricating oil pump type | Rotor type oil pump |
Lubricating oil label | 10W-30 SAE |
Lubricating oil capacity | 1.5-2.2L |
Clutch type | Dry-type monolithic clutch |
Engine dimension (LxWxH) | 404*418*563 mm |
Engine weight | 61kg |
Transmission | Manual |
Drive Train | Front engine, Front drive |
Dimension |
LxWxH | 3180*1450*1550 mm |
Wheelbase | 2050mm |
Fuel Capacity | 30L |
Ground clearance | 200mm |
Min. turning radius | 9 m |
Dry Weight | 560 kg |
Chassis System |
Material | Aluminum frames |
Braking system(F/R) | Disc Brake (F/R) Drum Brake |
Suspension System(F/R) | McPherson independent suspension |
Tires/Front/Rear | 155/65R13 |
Body color | RED, YELLOW, BLACK, BLUE, WHITE, GREEN |
Detailed Photos
Packaging & Shipping
Certificate
Customer Feedback
FAQ
1) What's the MOQ?
--3 units. But we can put 4 units into a 20ft container, so that we can have a lower shipping freight for each unit.
2) The transmission, what do you have?
-- We have manual transmission for gasoline model and automatic transmission for electric model.
3) Steering wheel assist system, can you install it for us?
-- Yes we can install it for you if you want, and only $350 charges for it.
4) If we want to be your sole agent in our market, what will you do to help us?
-- First you make the initial order to do the marketing, we will provide you a three-months protection. Then we can come to the agreement.
5) Can it be ok for Europe market?
-- Definately yes, we have got EEC certificate with COC document for registration.
6) We are a right hand drive country, can you make it?
-- Yes, both RHD and LHD available. Welcome to pay a visit to us
