Automatic Bridge Type Marble and Granite Stone Polishing Machine
| US$7,900.00-14,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
QSM-110/200
Precision
High Precision
Application
Granite, Marble
Type for Grinding Machine
Disc Grinding Machine
Grinding Machine Type
Vibration Polishing Machine
Grinding Method
Wet Grind
Certification
ISO, CE
Condition
New
function
Polishing granite and marble slab
Operation
Auto and easy
main motor
11kw
color
customer needing
Transport Package
Water-Proof Plastic Film Package
Specification
4500*3500*2100mm
Trademark
Great Base
Origin
Fujian, China
HS Code
84642090
Production Capacity
400sets/Year
Product Description
Features:This machine is mainly applied to grind and polish marble and granite slabs. It is mainly suitable for coarse grinding, fine grinding and polishing marble and granite slabs. Being pendulum which is advanced internationally now days, the grinding heads are controlled by air cylinder to elevate. Their longitudinal and transverse movements are enabled by cyclical pinwheel reduction motor. Having a PC programmer inside the electrical cabinet, it can grind the slabs in the way of longitudinal wave, transverse wave and cycle wave. Therefore, it features low cost and high grinding efficiency.
Technical Data:
| Name | Unit | QSM-110 | QSM-200 |
| Max. processing size | mm | 3000*1100 | 3200*2000 |
| Max. thickness of slabs | mm | 60 | 60 |
| No. of grinding heads | pc | 1 | 1 |
| Lateral running speed of grinding head | Mm/min | 3780 | 3780 |
| Lateral running speed of working table | Mm/min | 3300 | 3300 |
| Main motor power | kw | 11 | 11 |
| Overall dimension(L*W*H) | mm | 4500*2400*2100 | 4500*4340*2420 |
| Total weight | kg | 2700 | 4200 |
| Air consumption | m³/min | 0.1 | 0.1 |
