2" High Pressure Diesel Pump, High Efficient
| US$170.00 | 10 Pieces (MOQ) |
Basic Info.
Model NO.
DP20H, DP30H, DP40H
Pressure Medium
Water
Type
Handheld
Position of Pump Shaft
Vertical Edge
Certification
CE
Dp20h-C
2"Iron Cast Diesel High Pressure Pump
Dp30h-C
3"Iron Cast Diesel High Pressure Pump
Sp20d,Sp30d,Sp40d
2′3′4′ Clean Aluminum Water Pump
Dp40h-C
4" Iron Cast High Fire Fighting Pump
Dp20h,Dp30h,Dp40
2"3"4" Aluminum High Pressure Pump
Transport Package
by carton
Specification
diesel high pressure pump 2" 3"
Trademark
hot-stuff
Origin
fujian
HS Code
8413781009
Production Capacity
3000pcs/month
Product Description
Diesel water pump powered by 4-stroke diesel engine. High output trash pumps capable of handling grancile up to 1.5" diameter, removable front cover ofr easy clearing and maintenance, highly effective mechanical seal compact in structure and light in weight, aluminum alloy high presure easily.| model no: | DP20H | DP30H | |||||||
| pump type: | centrifugal pump/self-priming | ||||||||
| Self-priming time(s/4m) | 60 | 65 | |||||||
| engine type: | single-cylinder vertical direct injection 4-stroke air cooled diesel | ||||||||
| powered by diesel engine: | 5HP | 9HP | |||||||
| Heavy-duty fuel frame protection | |||||||||
| suction and discarge port: | 2" | 3" | |||||||
| engine speed: | 3600rpm | ||||||||
| max displacement: | 30m3/h | 40m3/h | |||||||
| lift H max: | 55m | 70m | |||||||
| max suction head(m): | 7m | 8m | |||||||
| engine model: | 178F | 186F | |||||||
| engine bore xstroke | 78x62mm | 86x70mm | |||||||
| engine displacement: | 296ml | 296ml | |||||||
| start model: | manual or electrical start | ||||||||
| fuel tank capacity: | 3.5L | 5.5L | |||||||
| cooling system: | forced air | ||||||||
| lub oil capacity: | 1.1L | 1.65L | |||||||
| connector of infall or outfall: | yes | ||||||||
| seal ring: | yes | ||||||||
| hoop: | yes | ||||||||
| size: | 590x475x540 | 660x490x610 | |||||||
| qty/20ft container | 144pcs | 96pcs | |||||||
