Factory Price Sinotruk HOWO 8X4 Concrete Pump Truck for Sale

Product Description

quipped with a powerful engine and advanced hydraulics, Howo concrete pump trucks can reach heights and distances that are unattainable with conventional concrete delivery methods. The truck's precise controls allow for accurate concrete placement, ensuring that your project is completed with maximum efficiency and quality. Using the highest quality materials and advanced technology, this pump truck is the perfect choice for delivering concrete to hard-to-reach areas.

Model of chassis			HOWO ZZ5437N5067C1 with ABS
Weight		42×103kg	Drive mode of chassis				8×4
Max. travel speed		80km/h	Cab with air-condition and sleeper
			Wheelbase		1-2 / 2-3 / 3-4 Wheelbase(mm)			1800 / 5000 / 1350
Overall height	Overall length	14000mm
	Overall width	2500mm	Tread		front wheel			2022mm
	Overall height	4000mm			rear wheel			1830mm
Engine	Engine	In-line; six-cylinder water-cooled after-cooling EFI diesel engine	Tire size					12.00R20
			Min. turning radius					12m
	Model of engine	WD615.96	Braking distance					10m/30km/h
	Output power	276KW 2200rpm		Form				Five section, folded, full hydraulic
	Max. torque	1500Nm/1100-1600rpm	Boom	Max. ground clearance				51.8m
	Emission standard	EUROIII		Diameter of conveying pipe				DN125
	Gearbox model	HW19710		Length of end hose				3m
	Displacement	9726ml		Section 1 boom		Length		11000
Pumping system	Drive mode	Hydraulic type				rotation		910
	Cylinder diameter ×stroke	φ140mm×2000mm		Section 2 boom		Length		9200mm
	Delivery cylinder diameter × stroke	φ230mm×2000mm				rotation		1800
	Valve type	Valve type		Section 3 boom		Length		9200mm
	Displacement in theory	125m3/h				rotation		1800
				Section 4 boom		Length		9200mm
	Pumping pressure in theory	8.5 Mpa				rotation		1800
				Section 5 boom		Length		9200mm
						rotation		2700
				Rotating range of placing boom				3650
	Pumping times in theory	26 times/min.		Max. placing radius				47.8m
				Max. placing height				51.6m
				Hydraulic system pressure				32MPa
			Lubricating method					Automatic grease lubrication
	Hopper capacity	0.6M3	Oil tank capacity					1000L
	Feeding height	1.40m	Control					Manual/ remote control
	System oil pressure	32Mpa	Max. water pressure of water pump					6MPa
	Slump constant	14cm~23cm	Water tank volume					650L
	Max. aggregate size	40mm	Cooling method of hydraulic oil					Air cooling
	High and low pressure pumping switch	Manual	Cleaning way of concrete pipe
								Washing/ dry-cleaning

The factory and the company are open, and we have received 1,000+ customers frommore than 100 countries around the world. Welcome customers to visit our companyand production factory.
Our trucks are popular in Africa,South Africa,The Middle East,South America,Southeast Asia.We have enough experience to solve any problems you may encounter.We have a professional after-sales team, which will solve your questions in time.
Company brief introduction:
We are established in 2010. The company is located in Jinan City, Shandong Province, where Sinotruk is located.Sincere to the customer and in good faith of quality is Deruna Heavy Truck Parts forever followed motto. It's the basement to be a human and do business. We take all responsibility for our products and service sincerely.
Main product: Our company specializing in the manufacturing and wholesale of China National Heavy Duty Truck, Shaanxi Heavy Duty Truck, Beiben truck, Foton truck and its related accessories. We mainly engage in various accessories products such as truck parts, cylinder blocks, crankshafts, diesel engines.
1.Power parts, including engines and peripheral parts [such as starters, generators, superchargers, various filter elements, etc.
2. Driving Part [also called transmission part], including clutch, gearbox, transmission shaft, axle, etc.;
3. Suspension part, including front and rear steel plates and fasteners, balance shaft, thrust rod, etc.
4. Steering part, including steering gear and Horizontal pull rods, etc.
5. Electrical appliances and valve parts, including various types of electrical switches, wiring harnesses, bulbs, and various braking components (valves).
6. Control and cargo parts, namely cab and cargo compartment.
7. Frame [that is, the beam] and so on.
Overseas market at present: Our sales have averaged over 10 years of experience in exporting, and are proficient in all processes of business operation which can efficiently fulfill customer needs. We currently export to 37 countries, and the client partners from Russia, New Zealand, Fiji, Papua New Guinea, Malaysia, Zambia, South Sudan, United Arab Emirates, Zimbabwe, Colombia and so on. We can also help you to supply registration documents of the importing in different countries. Welcome new and regular customers to contact us to establish future business relationships and achieve common success.
We will We find the best transportation solution for you to reduce the transportation cost.
(1)Wax: Do wax spray process to against the trailer body suffer seawater corrosion during shipping
(2)Package: Stable fixing with steel wire,to protect the trailer during shipping
(3)Shipping: Reliable logistic service from famous freight supplier makes transport process safely and promptly
Q: What if I can not provide part number for reference?

A: If no part number, we can judge and quote the requested parts by engine name-plate or photos;
It would be great if you could provide us with the chassis number(VIN) so that we can provide a more comprehensive analysis and accurate quote feedback based on your truck model.

Q: Can we buy 1 pcs of truck parts for quality testing?

A: Yes, we are glad to send 1pcs item for quality testing if we have the truck parts of you need in stock.

Q: Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery.

Q: How do you make our business long-term and good relationship?

A: We keep good quality and competitive price to ensure our customers benefit;
We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

Q: How long is the production time of the goods?

A: We have sufficient stock of regular specifications for immediate delivery; Non-conventional specifications generally require stocking for about 7-10 days; Large quantities order need to be in stock for about 15-20 days.

Q: What is the packing?

A: Neutral packing of paper carton or wooden case. Or we customize the packaging according to your requirements
