Best Quality 3 Axis CNC Cutting Machine Tool

Product Description

Welcome to Nantong AJ Industry Limited! Feel free to inquire about our top-quality 3 Axis CNC Cutting Machine Tool. Visit our leading factory today!
Workshops:
Explore our Best Quality 3 Axis CNC Cutting Machine Tool for precision machining needs. Our Vertical Machining Center offers advanced CNC capabilities for industrial applications.
Product Description:
Nantong AJ Industry Limited offers the Best Quality 3 Axis CNC Cutting Machine Tool, featuring a VMC640 with a 950x400mm worktable and travel of 700x450x500mm. Ideal for precision machining needs.
Product Description
Specifications:
Spindle: BT40 10000rpm or 12000rpm from Taiwan
Travel: 900x600x700mm
Roller guideways: width 35/45/45mm from Hiwin/PMI
Hiwin ballscrew: diameter 40mm C3 class with lock nuts
ATC: OKADA brand with 24 tools, side-mounted, armless type
Chain type chip conveyor
Main Configuration & Accessories:
Resin sand casting, Meehanite HT-300
X, Y, Z rails with stainless steel telescopic cover
Roller type linear guideway from Taiwan
Ball lead screw from Taiwan
Belt-driven spindle (optional for direct-driven spindle)
Taiwan pneumatic cylinder
Taiwan ATC, umbrella and disc type available
Import bearings for leadscrews
Import coupling
Headstock Nitrogen balance system as an option
Full enclosed cover
Rigid tapping
Spindle center ring blast
Work lamp
Pilot lamp
USB and Internet interface
Manual pulse generator (MPG)
Centralized automatic lubrication system
Cooling system
Heat exchanger for electrical cabinet
Leveling blocks & bolts
Toolbox and tools
CNC controller options: KND, GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc
Standard Accessories:
All machines and standard accessories supplied by Nantong AJ Industry Limited except couplings, cables, electric panel, CNC system and motors, auxiliary panel, and transformer (motor housing supplied by Nantong AJ Industry Limited).

Fanuc 0i TF control system

Taiwan Spindle: 8000rpm

X/Y/Z axes: Fanuc servo drive motor

Main motor: Fanuc spindle motor

24 tools Umbrella type

USB for information transfer

Rough cutting of thread

Full closed cover

Automatic lubrication

Coolant system,

Work lamp,

Tri-color indication lamp

Air gun

Heat exchanger in cabinet

3-Axis linear guideway from Taiwan Hiwin

Ball leadscrew from taiwan Hiwin

Enhance your CNC cutting machine with optional accessories from Nantong AJ Industry Limited. Find the best quality 3 Axis CNC Machine Tool for sale, including advanced VMC milling machines and precision cutting equipment.

Automatic chip conveyor & chip bucket (Chain type)

Spindle direct driven, speed 12000 rpm

Spindle center water spray

Air conditioner for electricity cabinet

Automatic chip conveyor & chip bucket (Screw type)

Spindle oil cooling

Nitrogen balance cylinder

4th Axis or 5th Axis

Export Certificate for Nantong AJ Industry Limited's Best Quality 3 Axis CNC Cutting Machine Tool. Top-notch industrial machinery for precision cutting needs.
