Professional High Quality Industrial Stainless Steel Food Pharmaceutical Chemical Horizontal Single Shaft Sigma Blade Kneading Mixer

Product Description

Product Description
1. Introduction:
Single shaft sigma blade mixer machine is especially used to mix paste materials, mix powder, granules, particles in pharmaceutical, foodstuff, chemical fields. such as flour, dough, soap, etc.
2. Working principle and features:
Single shaft sigma blade mixer machine can reach good mixing effect by mechanical driving to push the material to move to and from inside the kneading machine.
You can control the mixing time by setting the time relay between 0~999 minutes on the dough kneading mixer, the sigma blade mixer machine will stop automatically when time is up.
Then you can adjust the tank to rotate till its reaching a proper position and push the output button to make the Z or sigma shaped blade blender reverse to discharge the materials automatically.
Detailed Photos
Product Parameters

(SSM Series) Single Shaft Sigma Blade Kneader Mixer of HIGAO TECH
Model	Total volume	Loading volume	Sigma agitator	Discharger/angle	Dimension(L×W×H)	Weight
SSM-50	50L	30L	1.5kw/24rpm	0.18kw/<105°	1265×430×720mm	200kg
SSM-100	100L	60L	2.2kw/24rpm	0.55kw/<105°	1580×500×830mm	300kg
SSM-200	200L	120L	4kw/24rpm	0.75kw/<105°	1850×600×1000mm	450kg
SSM-300	300L	180L	5.5kw/24rpm	1.1kw/<105°	2160×700×1200mm	550kg
SSM-400	400L	240L	7.5kw/24rpm	1.5kw/<105°	2280×700×1250mm	700kg
SSM-500	500L	300L	7.5kw/24rpm	1.5kw/<105°	2450×700×1250mm	800kg
SSM-600	600L	360L	11kw/24rpm	2.2kw/<105°	2500×900×1350mm	850kg
