CNC Vertical Type Drilling Machine (ZK5140 ZK5150)
| US$7,000.00-10,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
ZK5140 ZK5150
Controlling Mode
CNC
Number of Shaft
3
Hole Diameter
<50mm
Automatic Grade
Automatic
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
spindle taper
MT4
table size
1000X545mm
max drilling capacity
50mm
max torque of spindle
350
positioning accuracy
+0.025
Transport Package
Plywood Case
Specification
cast Iron
Trademark
Hoton
Origin
Shangdong, China
HS Code
8459699000
Production Capacity
10 Sets Per Month
Product Description
Hoton Machinery CNC Drilling Machine ZK5140 and ZK5150
1. Zk5140B and Zk5140B-1 vertical cnc drilling machine are universal drilling machine.the max drilling diameter is 40mm.
2.Zk5150B and Zk5150B-1 vertical cnc drilling machine are universal drilling machine.the max drilling diameter is 50mm.
3. The table of Zk5140B, Z5150B is fixed and The Zk5140B-1, Zk5150B-1 is cross table.
4. This machine also can enlarge hole,drill deep hole,tapping,boring and etc. except drilling hole.
5. This series machine have many advantages,such as high efficiency, good rigid,high precision,low noise, wide speed range..the machine which have cross table ,the table can manual feeding on cross ,longitudinal and lifting.
| Specification | Unit | ZK5140 | ZK5150 |
| Table size | mm | 1000X545 | |
| Area of worktable | mm | 850X400 | |
| Max drilling diameter | mm | φ40 | φ50 |
| T-slot width/quantity | mm | 18/3 | 18/3 |
| Spindle hole taper | MT #4 | MT #5 | |
| Spindle speeds | r/min | 31.5-1400/12 steps | |
| Power of spindle motor | kw | 3 | |
| Vertical travel of drilling head (manual) | mm | 360 | |
| Travel(X/Y/Z) | mm | 850/400/240 | |
| Distance from spindle nose to worktable | mm | 100-700 | 65-665 |
| Distance from spindle center line to column | mm | 335 | |
| Rapid travel rate X/Y/Z | m/min | 15/15/3.5 | |
| CNC system | KND system | ||
| Max torque of spindle | N.m | 350 | |
| Max feed resistance | N | 10000 | 12000 |
| Positioning accuracy | mm | ±0.025 | |
| Repositioning accuracy | mm | ±0.015 | |
| Contact Us: |
Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
