Std Htd T2.5 T5 T10 At3 At5 Dt5 PU Moulded Timing Belt

Product Description

Product Description
Kaitai Moulded PU Timing Belt is cast from thermosetting polyurethane material ,which gives the belt superior mechanical properties , chemical properties , and thermal stability . Various of reinforced cord serve as the tension layer of the belt , paired with high-precision full-size molds , endowing the timing belt with excellent dimensional stability and abrasion resistance . The product is suitable for high-strength, high-precision and high-speed transmission .

Features:

Clean & Environmentally friendly Fine size stability High abrasion resistance Low noise Excellent resistance to ageing, hydrolysis, UV and ozone. Efficient transmission ,with a maximum speed of 20,000RPM Nylon / Steel / Kevlar Cord availab
Applications: Home Appliances Office Automatic Equipments Swimming Pool Cleaning Robots Robotic Arms Semiconductor Industry Robotics and plotters
Detailed Photos

Product Name :	S3M PU Moulded Timing Belt
Color :	black , natural or customized
Material :	polyurethane
Pitch :	3mm
Temperature :	-30 - 85 degree

S3M

ADVANTAGES :
Available Typies

Type	No. of teeth	Length (mm)	Type	No. of teeth	Length (mm)
S3M108	36	108	S3M375	125	375
S3M114	38	114	S3M396	132	396
S3M120	40	120	S3M405	135	405
S3M129	43	129	S3M414	138	414
S3M144	48	144	S3M417	139	417
S3M150	50	150	S3M420	140	420
S3M162	54	162	S3M426	142	426
S3M174	58	174	S3M432	144	432
S3M177	59	177	S3M453	151	453
S3M180	60	180	S3M459	153	459
S3M183	61	183	S3M468	156	468
S3M186	62	186	S3M480	160	480
S3M192	64	192	S3M486	162	486
S3M201	67	201	S3M492	164	492
S3M210	70	210	S3M504	168	504
S3M213	71	213	S3M513	171	513
S3M222	74	222	S3M516	172	516
S3M225	75	225	S3M519	173	519
S3M231	77	231	S3M522	174	522
S3M234	78	234	S3M525	175	525
S3M237	79	237	S3M528	176	528
S3M246	82	246	S3M531	177	531
S3M252	84	252	S3M537	179	537
S3M258	86	258	S3M540	180	540
S3M276	92	276	S3M543	181	543
S3M279	93	279	S3M546	182	546
S3M282	94	282	S3M549	183	549
S3M285	95	285	S3M555	185	555
S3M294	98	294	S3M564	188	564
S3M300	100	300	S3M573	191	573
S3M306	102	306	S3M585	195	585
S3M315	105	315	S3M588	196	588
S3M318	106	318	S3M594	198	594
S3M333	111	333	S3M600	200	600
S3M336	112	336	S3M612	204	612
S3M342	114	342	S3M615	205	615
S3M351	117	351	S3M642	214	642
S3M357	119	357	S3M669	223	669
S3M363	121	363	S3M672	224	672
S3M366	122	366	S3M684	228	684
S3M372	124	372	S3M696	232	696
			more available

Company Profile
ZHEJIANG SANMEN KAITAI BELT CO.,LTD
* Who Are We * What We Supply * Our Amis
-- Started since 1987 -- Moulded Timing Belts -- Focus on technology innovation
-- 30+ years experience -- Open-end Timing Belts -- World's leading transmission solution exterprise
-- 30,000 square meters factory area -- Ribbed Belts
-- 10,000,000+ pieces of annual production capacity -- Robotics Belts for outdoor


Certifications

Packaging & Shipping
Available Packing : Carton / Poly Bags / Pallets / Wooden case / Customized

Shipping : By sea / By Air / By Train / By Express
Our Advantages
1. Delivery on time : in the past 5 years , the proportion of delayed deliveries is less than 3%
2. Product Quality : we produce belts for a big Home Appliances' facotry , the rejected rate is less than 1% during 3 years .
3. Research & Development : more than 10 people R&D team to ensure every year with new technical .
4. Cost : Bulk raw material purchase , and molds in our own factory result in product costs that are generally 2% lower than those of our peers
FAQ
1. Can I have a sample order for PU Timing Belt ?
yes , sample order is available to test and check quality
2. Can you accepted the customized timing belt ?
yes , customized timing belt is accepted .
3. Is it ok to print our logo on PU timing belt products ?
Yes , just inform us your logo or design before mass production
4. what is the use of PU timing belt ?
Polyurethane open-ended timing belts offer invaluable benefits to the food and beverage industry, particularly in food contact packaging applications.
5. which is better rubber belt or PU belt ?
Polyurethane timing belts are more wear-resistant than rubber timing belts , and are more resistant to chemicals such as acides and alkalis.
6.Are PU belts durable ?
PU belts are able to withstand high loads and are known to have a long service life , even under demanding conditions . PU belts are also resistant to abrasion and require minimal maintenance , making them a cost-effective choice for many industries .
7. how do I choose a timing belt ?
* Determine the peak torque for your drive
* Determine the largest pulley diameters that can be utilised , considering the space limitations and drive ration of your system
* Select the belt tooth profile
* Calculate the teeth in mesh
8. Are all timing belts the same size ?
there are a lot of different variables for belt sizing - width,number of teeth (pitch),material,etc .
