1080P Drainline/ Pipe /Sewer Camera Inspection with 7inch Visor DVR Recorder IDS908-V8

Product Description

1080p drainline/ pipe /sewer camera inspection with 7inch visor DVR recorder iDS908-V8
Model#iDS908-V8

Description of our underwater iDS-908V8
DS-908 all in one 7 "1080P AHD CCTV Test with HD record and display function is new generation product with four mixed coaxial from 3rd Eye Electronics Co., Ltd. DVR visor can be remove when you don't need it.
This 1080P AHD CCTV Tester is compatible with FHDTVI, AHD and other coaxial HD specifications, can access FHDTVI, CVI, AHD and analog signal. And this 1080P AHD CCTV Tester integrates multinomial IT high-tech.
MCV8 is a HD micro underwater camera with IP68 waterproof rate. The default cable is 0.5m. After unique design and continuious test, this camera cable can be made up to 200 meters. It can standwith 15MP.
1080P AHD monitor to connect MCV8 is suitable insepction camera system to be used in sewer, guttering, chimney, pipeline, deepwater, miner inspection.
Instructions:
1. Connect the long cable underwater camera to the HD DVR monitor by aviation plug head.
2. Turn on the DVR recorder and check the video.
3. If you want to record the video, you need insert the SD card into the DVR
Feature of our underwater IDS-908V8
*Focus: 3cm to 8m
*Light source: 8pcs white lighting led
*SENSOR :1/4 CMOS SYSTEM:PAL/NTSC
*RESOLUTION:520TVL 768(H)×576(V)
*LENS & VIEW ANGLE : F1.2/90°
*Waterproof Rate: IP68
*Led control by monitor
*7-inch 90 ° view(1024x600pix) TN screen
*Recording :Loop recording and NO-Loop recording
*Record resolution: 480P,720P,1080P
*Support H.264 encoding.
*Storage: 128GB
*4x zoom monitoring
*Video input:HD TVI,CVI,AHD,CVBS
*Video output:composite
*Built-in 7500mAh high capacity Li-battery
*Working Voltage: 5-12V
*Support 12 Voltage power output for camera
*Supports multi-language
Specification of our underwater IDS-908V8
Camera:

Items	Value
PICK UP ELEMENT	Single chip 1/3 CMOS
SYSTEM	NTSC /PAL
NUMBER OF PIXEL	NTSC:656(H)×492(V) PAL: 786(H)×576(V)
SENSOR DIMENSION	4.75mm(H)×3.55mm(V)
HORIZONTAL RESOLUTION	Approximately 520TV Lines
SENSITIVITY	MCV8-LED: 0.00Lux(Default) MCV8-IR940:0.00Lux MCV8-IR850:0.00Lux
LENS & VIEW ANGLE	0.5mm F1.2 / 90 °
LED Control	Controlled on DVR monitor
LIGHTS SOURCE	8 LED: show white LED lights(Default) 8 IR940nm: show invisible IR lights 8 IR850nm: show red dot IR lights
VIDEO OUT	1.0V p-p/75ohm
WEIGHT	12g
SIZE	15m: 18*32mm(DxL); 50m/100m/200m: 18*50mm(DxL)
WORK CURRENT	DC12V:35mA(Lamp Off)/ 85mA(Lamp On)
POWER REQUIREMENT	DC5-24V
OPERATING TEMPERATURE	- 10° C ~ +50°C ,less than 90% RH
WATERPROOF RATE	IP68
CABLE LENGTH	15~200meters
CONNECTION	PIN1 Red DC12V PIN2 Black GND PIN3Yellow VIDEO OUT

DVR Monitor:

Items		Value
Display	Resolution	1024 X 600 Pixel
	View angle	Full view 90 °
	Brightness	350 cd/ squre meters
Video	Video input	Full HDTVI,AHD,CVI,CVBS
	Video transmitting range	800 meters for TVI 1080P signal
	Video delay time	<0.1s
	Power output	12V 300mA
	Video LED control output	LED On/Off
	Video Storage Pixels(16:9)	1920* 1080
	Video compress	H.264
	Video storage Format	AVI
Audio	Audio Frequency Range	20HZ-20KHz AAC
	Audio Compression Format	AAC
Photo	Photo storage Format	JPG 5.0 mega :2560(H)×1920(V)
Storage	External SD card	TF card 2-128GB (Optional)
	128GB Recording time	18-60 hours
Operating System	PC	Windows & Mac OS
	Port	USB 2.0
Items		Value
	Language	Multiple
Power	Working voltage	DC :5-12V
	Working Current	2A
Battery	Built-in Li Battery	7000mAh
	Working time	≥5hours
Dimension:(LxWx H)	DVR main part	178mm x 122mm x 17mm
	DVR main part	350 g

Detail Photo Show of our underwater IDS-908V8

Package Content of underwater IDS908-V8
1 x Mini underwater camera and AHD monitor
1 x User Manual
2 x 12V Power adapter
1 x AV cable
1 x Package box
