Diesel Version China Trailer Concrete Pump Delivery Pump Machine
| US$25,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HBT9018K
Type
Concrete Mixer
Shotcrete Type
Wet
Machining Process
Hydraulic
Structure
Rotor Type
Productivity
240m²/h
Feeding Height
1400mm
Vibrating Amplitude
2.6mm
Certification
CE
Condition
New
Color
Yellow
Concrete Delivery Value
115/60 M3/H
Hopper Capacity/Filling Height
0.6/1370
Rate Power
186/2100
Transport Package
Nude Package
Specification
8165*3016*3485mm
Trademark
Evangel
Origin
China
Production Capacity
100 Sets/Month
Product Description
Trailer concrete pump HBT9018K concrete pump machine for sale1. By comprehensively incorporating switch-over control technology, the extraction and control of switch-over signal is totally done by hydraulic pressure, avoiding the unreliability brought by frequent electrical contact and harsh environment and reducing customers' later maintenance cost.
2. By adopting exclusive invariable reversing buffering technology in the industry, the pump displacement keeps unchanged during pumping and reversing and the main system unloads in low pressure, which thoroughly avoid such problems as long reversing time, great reversing impact and low service life of pump caused by frequent change of displacement during traditional reversing.
3. The use of equivalent bending moment design ensures uniform force, reliable sealing and greatly prolongs the service life of bearing ring, spectacle wear plate and cutting ring. The feature of unilateral wear makes the theoretical service life of rock valve once higher than that of S-valve.
| Description | Unit | Parameter value | ||
| Overall performance | Overall dimensions | mm | 6482×2100×2886 | |
| Total curb mass | kg | 7400 | ||
| Concrete delivery value | m3/h | 115/60 | ||
| Max. output pressure | Mpa | 18 | ||
| Pulling speed | km/h | Three-level road 8km/h | ||
| Road above two-level 16km/h | ||||
| Delivery distance(vertical/horizontal) | m | 250/1000 | ||
| Hopper capacity/filling height | m3/mm | 0.6/1370 | ||
| Concrete slump range | mm | 80-230 | ||
| Concrete delivery cylinder diameter/stroke | mm | 230/1600 | ||
| Power system | Main motor (diesel engine) | Model | BF6M1013 | |
| Rated power | kw/r/min | 186/2100 | ||
| Manufacturer | DEUTZ | |||
| Hydraulic system | Type | Open type | ||
| Pressure of hydraulic system | Mpa | 32 | ||
| Main oil pump | Model and type | 280 | ||
| Rated working flow | L/min | 560 | ||
| Manufacturer | KAWASAKI | |||
| Pumping oil cylinder diameter /stroke | mm | 170/1600 | ||
| Capacity of hydraulic oil tank | L | 600 | ||
| Mixing system | Large torque at low speed | |||
