Hot Selling Lifting Equipment High Efficiency Articulated Articulated Boom Diesel Lift Boom Lift Table
Basic Info.
Model NO.
ZMQBPT14C Lifting Platform
Application
Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism
Telescoping Lift
Carrying Capacity
Special Weight Level
Moves
Moving
Driven Type
AC
Running Mode
Moving
Feature
Insulating
Certification
CE, ISO 9001
"Overall Length (Folded) "
7.0m
Table Size
1.6*0.8m
Number of Working Arms
5 Sections
" Travelling Speed (Folded) "
4km/H
Mechanical Arm Swing
≤0.5%
Forearm Luffing Angle
130°
Weight
6596kg
Voltage
24V
Max. Working Height
14m
Max. Platform Height
12m
Max. Operating Radius
8m
Max. Spanning Height
6.6m
Driving Form
4X2X2
Engine Fuel Tank Volume
40L
Hydraulic Oil Tank Volume
120L
Transport Package
Wooden
Specification
Lifting Platform
Trademark
zhongmei
Origin
China
Production Capacity
1000 Sets Per Month
Packaging & Delivery
Package Size
410.00cm * 170.00cm * 270.00cm
Package Gross Weight
1000.000kg
Product Description
Product Description
Aerial working platforms make many difficult and dangerous jobs easier and are especially suitable for a larger range of continuous work at high altitude in airport terminals, stations, wharves, shopping malls, sports stadiums, community properties, factories, mines and workshops. This kind of aerial lifting platform is characterized by compactness, flexibility and convenience. A self-propelled aerial working platform can be used instead of scaffolding to reach the height you need and solve your hard works. Operated by only one person, the machine can complete lifting, forward, backward, steering, slewing and other actions, which greatly improves work efficiency.zmwm22
Product Parameters
| Overall dimensions | ZMQBPT10D | ZMQBPT12D | ZMQBPT14D | ZMQBPT16D | ZMQBPT18D | ZMQBPT20D | ZMQBPT22D |
| Overall length (folded) | 5.5m | 6.3m | 7.0m | 7.18m | 8.35m | 8.86m | 9.9m |
| Overall length (folded) | 1.65m | 1.78m | 1.93m | 2.18m | 2.2m | 2.25m | 2.4m |
| Overall height (folded) | 2.35m | 2.35m | 2.35m | 2.53m | 2.53m | 2.53m | 2.9m |
| Table size | 1.6*0.8m | 1.6*0.8m | 1.6*0.8m | 1.6*0.8m | 1.8*0.8m | 1.8*0.8m | 1.8*0.8m |
| Number of working arms | 5 sections | 5 sections | 5 sections | 5 sections | 5 sections | 5 sections | 5 sections |
| Travelling speed (folded) | 4km/h | 4km/h | 4km/h | 4km/h | 4km/h | 4km/h | 4km/h |
| Lifting Travelling speed (Unfolded) | 0.8km/h | 0.8km/h | 0.8km/h | 0.8km/h | 0.8km/h | 0.8km/h | 0.8km/h |
| Mechanical arm swing | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% | ≤0.5% |
| forearm luffing angle | 130° | 130° | 130° | 130° | 130° | 130° | 130° |
| Min.turning radius | Outer wheel 4.4m Inner wheel 2.25m | Outer wheel 4.4m Inner wheel 2.25m | Outer wheel 4.6m Inner wheel 2.35m | Outer wheel 4.6m Inner wheel 2.35m | Outer wheel 4.55m Inner wheel 1.85m | Outer wheel 5.2m Inner wheel 2.2m | Outer wheel 5.2m Inner wheel 2.2m |
| Height of the worktable from the floor (folded) | 620mm | 630mm | 300mm | 200mm | 90mm | 100mm | -200mm |
| wheelbases | 1907mm | 1907mm | 2017mm | 2017mm | 2100mm | 2540mm | 2540mm |
| track width | 1440mm | 1440mm | 1550mm | 1550mm | 1800mm | 1830mm | 1830mm |
| weight | 4900kg | 5800kg | 6596kg | 6900kg | 8550kg | 9200kg | 11000kg |
| Voltage | 24v | 24v | 24v | 24v | 24v | 24v | 24v |
| Tires specification | 28X9-15 Solid Tire | 28X9-15 Solid Tire | 28X9-15 Solid Tire | 28X9-15 Solid Tire | 28X9-15 Solid Tire | 28X9-15 Solid Tire | 28X9-15 Solid Tire |
| Tires size | 580mm | 580mm | 670mm | 670mm | 800mm | 800mm | 1000mm |
| Colour | yellow/customized | yellow/customized | yellow/customized | yellow/customized | yellow/customized | yellow/customized | yellow/customized |
| Max. working height | 10m | 12m | 14m | 16m | 18m | 20m | 22m |
| Max. platform height | 8m | 10m | 12m | 14m | 16m | 18m | 20m |
| Max. operating radius | 5.8m | 6.9m | 8m | 8.9m | 10.6m | 11.7m | 12.2m |
| Max. spanning height | 5.1m | 5.7m | 6.6m | 7.6m | 8.25m | 8.55m | 9.45m |
| Max. permissible chassis angle | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° | 1.5°/3° |
| Driving form | 4x2x2 | 4x2x2 | 4x2x2 | 4x2x2 | 4x2x2 | 4x2x2 | 4x2x2 |
| Max. Climbing | 25% | 25% | 25% | 25% | 25% | 25% | 25% |
| worktable load | 230kg | 230kg | 230kg | 230kg | 230kg | 230kg | 230kg |
| Max. number persons carried | Two people | Two people | Two people | Two people | Two people | Two people | Two people |
| worktable rtation angle (optional) | ±80° (overall length will increase 200mm ) | ±80° (overall length will increase 200mm ) | ±80° (overall length will increase 200mm ) | ±80° (overall length will increase 200mm ) | ±80° (overall length will increase 200mm ) | ±80° (overall length will increase 200mm ) | ±80° (overall length will increase 200mm ) |
| wind rating | Level 3-4 | Level 3-4 | Level 3-4 | Level 3-4 | Level 3-4 | Level 3-4 | Level 3-4 |
| Rotary angle of rotary table | 355°discontinuous | 355°discontinuous | 355°discontinuous | 355°discontinuous | 355°discontinuous | 355°discontinuous | 355°discontinuous |
| Type of power | rechargeable battery | rechargeable battery | rechargeable battery | rechargeable battery | rechargeable battery | rechargeable battery | rechargeable battery |
| Travel drive | 5.5kw | 5.5kw | 6.3kw | 6.3kw | 6.5 | 7.5kw | 7.5kw |
| Lifting drive | 4kw | 4kw | 4kw | 4kw | 5.5kw | 5.5kw | 5.5kw |
| Battery Voltage | 2v | 2v | 2v | 2v | 2v | 2v | 2v |
| battery capacity | 250ah | 250ah | 250ah | 250ah | 330ah | 330ah | 400ah |
| Battery Charger | 48v35A | 48v35A | 48v35A | 48v/40A | 48v/40A | 48v/45A | 48v/45A |
| Number of batteries | 24 pieces | 24 pieces | 24 pieces | 24 pieces | 24 pieces | 24 pieces | 24 pieces |
| Hydraulic oil tank volume | 60L | 60L | 60L | 60L | 80L | 80L | 80L |
Detailed Photos
