Estop High Quality CNC Duplex Milling Machine for Sale

Estop High Quality CNC Duplex Milling Machine for Sale

US$11,600.00-25,800.00 1 Piece (MOQ)

Basic Info.

Model NO.
TH-1600NC
Type
Worktable Milling Machine
Controlling Mode
CNC
Automatic Grade
Automatic
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Spindle Power
2*30kw
Machine Net Weight
31000kg
Max Loading Weight
9000kg
Spindle Speed
20-200rpm
Worktable Dimensions
1100mm*1100mm
Cutting Width
400mm-1600mm
Cutting Capacity
2mm*3mm
Control Axis Number
4
Spindle Taper
Nt60
Cutting Diameter
450/500mm
Precision for Dimension
0.02mm/300mm
Hydraulic Oil Tank
100L
Lubrication Oil Tank
3L
Transport Package
Wooden or Steel Box
Trademark
ESTOP
Origin
China
HS Code
8459590000
Production Capacity
15000sets/Year

Product Description

Product Description
Es Top: Professional made the excellent machine.

ESTOPCNC is a manufacturer, distributor and exporter of industrial master machinery and CNC machine tools in China. The company is headquartered in Dongguan city, Guangdong Province. Company by a group of in Taiwan and mainland China engaged in more than 20 years of CNC milling machine manufacturing engineers, maintenance technicians, relying on the powerful world factory location advantage and talent advantage, constantly promote the shift to China smart upgrade, made in China to intelligent manufacturing in China. Cost-effective milling machine, grinding machine, gantry processing center and other CNC machinery and equipment to the international market.
ESTOPCNC in the form of diversified, intelligent response to changing market environment, from the introduction of advanced technology, digestion and absorption innovation, to fully replace imported Japan, Taiwan machine tools, in domestic application, and after ten years of precipitation and accumulation, reverse exports to Japan, Taiwan province, North America, Europe and southeast Asia and the Middle East countries, combined with professional management operation system and professional international after-sales service team, won the user's praise and affirmation.
We will continue to bring you high quality and a variety of machining center equipment. Single-minded, do a good job of machinery, good service hexahedral processing, that is, the perfect quality and excellent global after-sales service!
Dongguan ESTOP Machinery Co., Ltd. Model:TH-1600NC
ESTOP CNC Duplex Milling Machine TH-1600NC
The ES-TOP series of duplex milling machines make it simple to machine precision angles and dimensions on blocks and plates for any application.
Easy to use input screen for parameters.
Once the cycle is complete, the clamps retract and the finished part can be removed and replaced with the next.
Learn from Japan's mature technology, continuously summarize and improve through long-term operational practice, develop and improve various functions, make it easier to operate, safer and faster.
Product Parameters
Specifications:
Items
Name
Specification
TWIN-HEAD CNC MILLING MACHINE TH-1600NCA
TH-1600NCA
Cutting capacity


Control axis number
4
Cutting capacity mm
2*3
Cutting width mm
400-1600
Worktable
Dimensions mm
1100*1100
Max loading weight
9000
Spindle
Spindle speed(Infinitely variable speeds) rpm:
20-200
Spindle power KW
2*30
Spindle taper
NT60
Cutting diameter mm
450/500
X axis
X/Y/Z axis motor power
3.0/3.0/4.0
Y axis
X/Y/Z Max feed speed m/min:
8000/8000/8000
Z axis
X/Y/Z Max cutting speed
6000/6000/6000
Accuracy
Squareness mm/300mm
0.02
Accuracy for dimension mm/300mm
0.02
Tank capacity
Hydraulic oil tank L
100
Lubrication oil tank L
3
Power
Power
AC380V 90KVA
Net weight
Machine net weight KG
31000


Configuration
ITEM
SPECIFICATIONS
QUANTITY
UNIT PRICE
AMOUNT
Main
CNC Twin head milling machine
NC Controller FANUC 0i-MF PLUS Touch screen
Model:TH-1600NCA(Gear type)
1 set


Standard configuration
1.Servo motor rotary worktable
2. Screw type automatic cleaning
3. Tools and tools car
4.Closed house sheet metal
5. Full set of cushion/clamp
6. Workpiece automatic measuring
7. 90?Workpiece positioning device
8. Air pressure system, blowing and automatic measurement
9. Working Light
10. Working status indicator light
11. Air cooling system electric box
12. Hydraulic system, single hydraulic cylinder clamping
13. Man-machine conversation system, automatic protection, diagnosis, display
1 set
2 sets
1 set
1 set
8 pcs
1 set
1 set
1 set

1 set
1 set
1 set
1 set

1 set


Accessories
1. Face cutter 450mm (R&L)
2. Transformer (380V to 220V)
3. Scrap car
2 sets
1 set
1 set



Our Main Products: High precision machining centers, Surface Grinding machine, Gantry grinding machine, NC band saw machine, CNC Circular plate sawing, CNC Vertical milling machine, CNC Duplex milling machine, Deep hole drilling machine, Horizontal milling centers, Vertical machining centers, High speed CNC turning centers, High Precision 5-Axis Vertical Machining Center We can customize models according to customer requirements, more Non-standard series please consult the manufacturer. Our Advantages

Our Service

Packaging & Shipping
Certifications


FAQ
FAQ
Q1. What is the payment Terms ?
A1: T/T, 30% initial payment when order ,70% balance payment before shipment; Irrevocable LC at sight. When we receive the advance payment, we will start to make production. When the machine is ready , we will take pictures to you after we got your balance payment. we will send the machine to you.
Q2.How can I choose the most suitable machines ?
A2: Please let us know your machining demand or machine size, we can choose the best model for you, or you can choose the exact model by yourself. You can also send us the products drawing, we will choose the most suitable machines for you.
Q3. What is the package of the machines?
A3: The machines standard packed by iron pallets or Fumigated wood with plywood films.
Q4. What is your trade terms?
A4: FOB, CFR, CIF or others terms are all acceptable.
Q5. What is your minimum order quantity and warranty?
A5: MOQ is one set, and warranty is one year. but we will offer lifetime service for machine.
Q6.When is the delivery time?
A6: We will delivery then within 15-60 working days after received your deposit. If some special machines will be some longer, we will give you the answer accordingly.
Q7: How to ensure the quality?
A7: 1.Firstly we choose best material for the processing.
2.Being and after processing, we will inspect the finished parts.
3.Machine finished, our company QC will test the machine as per customer requests.
Q8: How to deal with the after-sales service?
A8: 1. Technician available for training and installation at customer's company
2. Internet service by sending emails and videos, communicating online or calling
3. One year warranty. During the warranty period, we will sent damage of the machine parts (non-human factors)for free.
Q9: How do we get the training for the machines?
A9: You can send your people to our factory and we will offer training free of charge, or we can send our engineer to your place.
Q10: Where is your factory located?
A10: Our factory is located in Dongguan city and Chongqing city.

Es Top: Professional made the excellent machine.
