618s High Precision Artificial Manual Moding Grinding Wheel up and Down Manual Feed Surface Grinder Grinding Machine
| US$4,200.00-4,700.00 | 1 set (MOQ) |
Basic Info.
Model NO.
618S
Type
Surface Grinding Machine
Processing Object
Planar Mill
Abrasives
Grinding Wheel
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
High Precision
Condition
New
Table Dimensions
150*450mm
Grinding Wheel Size
180*16*32mm
Gross Weight
850kgs
Spindle Speed ( 60c/50c )
3600/3000 Rpm
Transport Package
Customizable
Specification
Customizable
Trademark
TRANSTAR
Origin
China
Product Description
Product DescriptionUnveiling a revolution in the realm of precision engineering, the High Precision Grinding Machine with Manual Control by Dongguan TranStar Machinery Co., Ltd. stands as a testament to impeccable craftsmanship and innovative design. Engineered for those who seek perfection in every detail, this state-of-the-art machine promises unparalleled accuracy and control, ensuring your projects meet the highest standards of quality and excellence. Detailed Photos
Product Parameters
| Mountings | Specifications | CSD-614S | CSD-618S |
| Processing Capability | Table Dimensions | 150×350 (6×14") | 150×450 (6×18") |
| Maximum Grinding Length | 370mm (14-3/4") | 470mm (18-3/4") | |
| Maximum Grinding Width | 160mm (6-1/3") | 160mm (6-1/3") | |
| Distance Between Spindle Center and Work Surface | 400mm (15-3/4") | 400mm (15-3/4") | |
| Standard Magnet Size | 150×300mm (6×14") | 150×460mm (6×18") | |
| Side-to-side Feed | Manual formation | 360mm (15") | 460mm (19") |
| Fore and Aft Feed | Manual feed ( per scale ) | 0.02mm (0.0005") | 0.02mm (0.0005") |
| Manual feed ( Per revolution ) | 5mm (1/5") | 5mm (1/5") | |
| Up and Down Feed | Manual feed ( per scale ) | 0.005mm (0.0002") | 0.005mm (0.0002") |
| Manual feed ( Per revolution ) | 1mm (0.05") | 1mm (0.05") | |
| Grinding Wheel | Grinding Wheel Size ( external diameter × width × aperture ) | 180×16×32mm (7"×2/3"×1-1/14") | 180×16×32mm (7"×2/3"×1-1/14") |
| Spindle Speed ( 60C/50C ) | 3600/3000 rpm | 3600/3000 rpm | |
| Motor | Spindle Motor (V3) | 1.5HP 60HZ/3600 rpm | 1.5HP 60HZ/3600 rpm |
| Weight | Gross Weight (About) | 690kgs (1518lbs) | 850kgs (1870lbs) |
In-Depth Product Details
