Automatic Pneumatic Paddy Husker Rice Huller Towin

Product Description

Through a pair of rubber rolls,which rotate in opposite direction and differential,paddy will be husked.The rice bran and the mixture of paddy and brown rice will be separated by rice bran separator.
Feature
1.The sensor is used to test the material level.There is a feed machine.When the material reaches a certain level,the machine will be turned on automatically.The feed gate will be opened and the husker will begin to work. If the material is discontinued or below the set level,the gate will be closed and the machine will be turned off automatically and stop working.
2.The material will be feed by vibration,which can ensure the even layer and flow of the meterial on the shedding plate,and keep stable the length and direction of the rubber rollers as well as the husking rate.
3.The air pressure is employed to adjust the rollers.The pressure between the rollers is even with less undulation,which helps stabilize the husking rate.
4.As the rubber rollers wear out,the long shedding plate can automatically trace and orient toward the target area between the two rollers till the rubber layer is used up.
5.The change gear box is used to adjust the speed in order to get the optimum technical parameters.

Technical Data:

Model	Capacity	Power	G.W.	N.W.	Package size
RHGQ25C	3-5.0t/h	7.5kw	750kg	600kg	1.05x1.4x2.2m
RHGQ36C	5.0-7.0t/h	11kw	1150kg	1000kg	1.35x1.55x2.26m
RHGQ51C	7.0-10t/h	15kw	1450kg	1300kg	1.4x1.55x2.26m

HUNAN TOWIN MACHINERY CO.,LTD founded in 1993,It is the best professional company in design, manufacture and sale of grain processing machine.
After 25 years of development, the company has trained a group of high calibre managers and a one-stop service team with a number of proficient, experienced technical backbone and R & D design people.The company has a group of professional technicians to provide 15-1000Ton per day rice processing engineering design for users, and has a group of experienced installation team to provide high-quality and efficient equipment installation, and after-sales service for users.
The company is renowned for its reliable product quality, mechanical stability and considerate technology service. Its products sell well all over the country, and are exported to Southeast Asia, South America, Africa and other countries and regions.
