US$2.00-2.50
|
100 kg
(MOQ)
|
Basic Info.
Model NO.
304 Stainless Steel sheet
Grade
201 304 316 321 310S 2205 2507 410 430
Certification
ISO, RoHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
Transport Package
Wooden Pallet
Specification
1219*2438/1500*6000
Trademark
TISCO POSCO Baosteel
Production Capacity
50000t
Product Description
Product Description
Product Parameters
Grade | 201 304 316 321 309 310S 2205 2507 410 420 430 440 409 630 17-4 |
Stainless Plate and sheet Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
Standard | ASTM A240 / ASME SA240 ASTM/ASME 240/480,JIS 4305,DIN EN 10088-2JIS, AISI, ASTM, GB, DIN, EN, etc |
Stainless Steel Plate and sheet Length | 1000mm-13000mm or as required |
Stainless steel Plate Width | 1000mm-1219mm-1500mm-1800mm-2000mm-2500mm or as required |
Stainless steel Plate Thickness | 0.3 to 120mm or as required |
ASTM A240 Stainless Steel 304 Plate Process | Hot/ Cold Rolled/forging |
Stainless steel Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM A240Stainless steel sheet, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
Stainless steel Sheet ASTM | ASTM A240 |
Stainless steelSheet AMS | AMS 240 |
Tolerances of width and thickness | ASTM-ASME-GB-EN-DIN-JIS |
Stainless steel Plate standards and approvals | EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 EN ISO 9445 ASTM A 480 ASTM A 959 ASME IID |
Stainless steel Plate & Sheet Sizes | 1000 x 2000 mm, 1220 x 2440 mm, 1500 x 3000 mm, 2000 x 2000 mm, 2000 x 4000 mm,1500*6000,Cold rolled 304 Stainless Plate 0.5-6.4 mm,Hot rolled 304 Stainless Plate 3.0-60.0 mm |
Stainless steel Plate Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard ASTM A240Stainless Steel Sheet suppliers |
Cutting | To provide a comprehensive service, we use a variety of cutting methods, including:Laser Plate Cutting,Plasma Plate Cutting,Oxy-propane Flame Cutting |
Plasma profiles | As per customer's drawings |
Value added services for 304 Stainless Plate | Laser cutting, Waterjet cutting, Plasma cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing. |
Manufacturer | POSCO, Aperam, ATI, Baosteel, TISCO, ArcelorMittal, VDM, Nippon Metal, Tsingshan, Delong. |
China Stainless steel sheet Manufacturer | ASTM A240Stainless Steel Stainless steel sheet: material 3/16″ [5.00 mm] and over in thickness and over 10″ [250 mm] in width;Stainless Sheet: material under 3/16″ [5.00 mm] in thickness and 24″ [600 mm] and over in width;Steel Stainless Stainless steel sheet: Steel Stainless Clad plate is a composite steel plate made by bonding Stainless Plate, etc.ASTM A240Stainless SteelStrip: cold-rolled material under 3/16″ [5.00 mm] in thickness and under 24″ [600 mm] in width. |
Stainless steel sheet Origin | CHINA |
Packing of Stainless steel sheet | Bundles with waterproof cloth outside or plywood box |
Test | UT, SGS testing, TUV etc |
Why buy Stainless steel sheet from DAXUN? | Free quote,Free sample,EN 10204 3.1,Mill Test Certificate is supplied with shipment,NABL Approved Lab Reports,Any third party inspection is accepted,Tested to ASTM A923 Method "C" or ASTM G48 Method "A".Minimum Nitrogen content and Ferrite Count TestGrade: AISI 304/S30400 |
Manufacturing: cold-rolled plate, hot-rolled plate, forged plate |
Standard: ASTM, ASME, GB, DIN, JIS, ISO, EN, BS |
Type: cold-rolled thin plate, hot-rolled thick plate |
Surface: 2B, NO.1, NO.4, HL, BA, 8K, etc. |
Length: 2438mm3048mm6000mm can be customized |
Origin: TISCO, Baosteel, Posco, Tsingshan, Delong |
Outstanding Flatness and Precision
Daixun Alloy's stainless steel plate products exemplify unparalleled flatness and thickness accuracy. Leveraging a rigorous quality control system, we produce stainless steel plates with remarkable uniformity. These plates boast superior formability and exceptional corrosion resistance, meeting the highest industry standards.
Surface Finishing
Employing the latest state-of-the-art automatic control technology, we continually refine our stainless steel plate production processes. This enables us to roll the steel plates under optimal conditions, resulting in finely processed surfaces with extraordinary glossiness. The exceptional surface quality of our products has received unanimous acclaim from our customers.
Stringent Quality ControlAt Daxun, we meticulously cut and finish high-quality stainless steel sheets to meet precise size specifications. Our stainless steel sheets come fully certified, backed by our membership in BSSA and ISO 9001 certification. We source these sheets from dependable factories and enforce stringent quality control measures from production to delivery. This rigorous process ensures that you receive products that exceed your highest expectations.
Stainless Steel Plate Surface Description
Finish Designation | Method and degree of finish |
No.1 | After hot rolling, heat treatment, pickling or other equivalent treatment is applied. |
No.2D | Annealing and pickling are performed after cold rolling; material is soft with surface of silver-white luster; used for general applications and deep drawing. |
No.2B | After 2D finish, skin pass rolling is performed to obtain a more suitable luster; the surface becomes very exquisite; used for general applications. |
No.3 | Intermediate 100-120 grit finish; used for applications in which surface polishing is performed after shaping. |
No.4 | General 150-180 grit finish; used for restaurants and kitchen equipment and tools. |
#240 | 240 grit finish; used when a finer finish than No. 4 is required; typically for restaurants and kitchen equipment and tools. |
#320 | 320 grit finish polished product. |
HL | This finish is performed by continuous linear polishing using an abrasive of appropriate grain size; mainly used for architectural applications. |
BA | Achieved by performing bright annealing after cold rolling and then skin pass rolling to obtain even greater reflectance; provides excellent corrosion resistance; used for household appliances, kitchen equipment, and automobiles. |
8K | Through multiple grinding, it achieves very high brightness and smoothness, like a mirror. |
Packaging & Shipping
Company Profile
Certifications
304/304L/304LN/304H stainless steel Shhet/plate composition |
Grade | 304 | 304L | 304LN | 304H |
UNS Designation | S30400 | S30403 | S30453 | S30409 |
Carbon (C) Max. | 0.08 | 0.030* | 0.03 | 0.04 - 0.10 |
Manganese (Mn) Max. | 2 | 2 | 2 | 2 |
Phosphorous (P) Max. | 0.045 | 0.045 | 0.045 | 0.045 |
*** (S) Max. | 0.03 | 0.03 | 0.03 | 0.03 |
Silicon (Si) Max. | 1 | 1 | 1 | 1 |
Chromium (Cr) | 18.0-20.0 | 18.0-20.0 | 18.0-20.0 | 18.0-20.0 |
Nickel (Ni) | 8.0-11.0 | 8.0-11.0 | 8.0-11.0 | 8.0-11.0 |
Molybdenum (Mo) | - | - | - | - |
Nitrogen (N) | - | - | 0.10-0.15 | - |
Iron (Fe) | Bal. | Bal. | Bal. | Bal. |
Other Elements | - | - | - | - |
316/316L316H stainless steel Shhet/plate composition |
Grade | | C | Mn | Si | P | S | Cr | Mo | Ni | N |
316 | Min | - | - | - | 0 | - | 16 | 2 | 10 | - |
Max | 0.08 | 2 | 0.75 | 0.045 | 0.03 | 18 | 3 | 14 | 0.1 |
316L | Min | - | - | - | - | - | 16 | 2 | 10 | - |
Max | 0.03 | 2 | 0.75 | 0.045 | 0.03 | 18 | 3 | 14 | 0.1 |
316H | Min | 0.04 | 0.04 | 0 | - | - | 16 | 2 | 10 | - |
max | 0.1 | 0.1 | 0.75 | 0.045 | 0.03 | 18 | 3 | 14 | - |
321/321H stainless steel Shhet/plate composition |
Grade | 321 | 321H |
UNS Designation | S32100 | S32109 |
Carbon (C) Max. | 0.08 | 0.04-0.10 |
Manganese (Mn) Max. | 2 | 2 |
Phosphorous (P) Max. | 0.04 | 0.04 |
*** (S) Max. | 0.03 | 0.03 |
Silicon (Si) Max. | 0.75 | 0.75 |
Chromium (Cr) | 17.0-20.0 | 17.0-20.0 |
Nickel (Ni) | 9.0-12.0 | 9.0-12.0 |
Molybdenum (Mo) | - | - |
Nitrogen (N) | 0.1 Max. | 0.1 Max. |
Iron (Fe) | Bal. | Bal. |
Other Elements | Ti=5(C) to 0.70% | Ti=4(C) to 0.60% |
310/310S stainless steel Shhet/plate composition |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24.00 - 26.00 | 0.10 max | 19.00 - 21.00 | 54.7 min |
SS 310S | 0.08 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 - 26.00 | 0.75 max | 19.00 - 21.00 | 53.095 min |
For more information on stainless steel rods, please contact Daxun: Discover the superior quality and unmatched performance of our stainless steel rods by reaching out to our expert team at Jiangsu Daxun Alloy Co., Ltd.
Mechanical properties of various grades of stainless steel plates: Learn about the distinct mechanical properties that make each grade of our stainless steel plates stand out. Our in-depth analysis ensures you select the right material for your specific needs.
Tensile Strength | Yield Strength | | | | | | |
Alloy | UNS Designation | Spec. | psi | MPa | ksi | psi | MPa | ksi | Elongation in 2 inches (min.) % | Grain Size Req. | Max. Hardness | Modulus of Elasticity (x106 psi) |
304 | S30400 | A249, A312 | 75,000 | 515 | 75 | 30,000 | 205 | 30 | 35 | - | 90 Rb | 28 |
304L | S30403 | A270 A312 | 70,000 | 485 | 70 | 25,000 | 170 | 25 | 35 | - | 90 Rb | 28 |
304LN | S30453 | A249, A688 | 75,000 | 515 | 75 | 30,000 | 205 | 30 | 35 | - | 90 Rb | 28 |
304H | A30409 | A249, A312 | 75,000 | 515 | 75 | 30,000 | 205 | 30 | 35 | 7 or coarser | 90 Rb | 28 |
The Mechanical Properties of grade 316L Stainless Steel are displayed in the following table. |
Grade | Tensile Str | Yield Str | Elong | Hardness |
(MPa) min | 0.2% Proof | (% in 50mm) min |
| (MPa) min | | Rockwell B (HR B) max | Brinell (HB) max |
316 | 515 | 205 | 40 | 95 | 217 |
316L | 485 | 170 | 40 | 95 | 217 |
316H | 515 | 205 | 40 | 95 | 217 |
| Tensile Strength | Yield Strength | | | |
Alloy | UNS Designation | Spec. | psi | MPa | ksi | psi | MPa | ksi | Elongation in 2 inches (min.) % |
321 | S32100 | - | 75,000 | 515 | - | 30,000 | 205 | - | 35 |
321H | S32109 | - | 75,000 | 515 | - | 30,000 | 205 | - | 35 |
Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
310S | 7.9 g/cm3 | 1402 °C (2555 °F) | Psi - 75000 , MPa - 515 | Psi - 30000 , MPa - 205 | 40% |
Grade | Tensile Strength | Yield Strength | Elongation | Hardness |
(MPa) min | 0.2% Proof | (% in 50mm) min |
| (MPa) min | | Rockwell C (HR C) | Brinell (HB) |
UNS S31803 / 2205 | 621 | 448 | 25 | 31 max | 293 max |
UNS S32205 / 2205 | 621 | 448 | 25 | 31 max | 293 max |
Grade | Property | Value |
2507/ S32750 | Density (g/cm3) | 7.8 |
0.2% Offset Yield Strength | 80 ksi |
Ultimate Tensile Strength | 116 ksi |
0.1% Offset Yield Strength 0.2% | 91 ksi |
Elongation in 2 inches, % | 15% |
Hardness Rockwell C | 32 |
Impact Energy | 74 ft.-lbs |
Density | 0.28 lb per inch3 |
Modulus of elasticity | 28 x 10(6) psi |
Coefficient of thermal expansion | 7.2 x 10(-6) per of at 68 to 212 of |
Thermal conductivity | 8.7 Btu/hr ftoF |
Heat capacity | 0.12 Btu/ lb oF |
Electrical resistivity | 31.5 x10(-6) ohm-inch |
For more information on stainless steel rods, please contact Daxun: Experience the excellence of Jiangsu Daxun Alloy Co., Ltd. Reach out today to learn more about our high-quality stainless steel rods and how they can meet your engineering and construction requirements.FAQ
Q1: What products can you offer?
A: We proudly offer a diverse range of steel types including 310S, 316L, 304, 304L, 201, 904L, 316H, and 316. Additionally, we have 316L 300 series.
400 series steels and duplex stainless steels such as 2205, 2304, 2101, and 2507 are also available. Our high-nickel alloys include 904L, 800H, and 600H.
Q2. Can you produce the products according to my own drawings?
Absolutely, we can tailor our products to meet your specific drawings, ensuring they fulfill your highest expectations.
Q3. How does your factory manage quality control?
Quality is our utmost priority. We diligently oversee every step of the manufacturing process from inception to completion to ensure superior quality.
Q4. Can I request to change the form of packaging and transportation?
Yes, we can accommodate changes in packaging and transportation as per your request,
although you will need to cover the additional costs and any price differences incurred.
Q5. How does your factory manage quality control?
Quality remains our top priority. We consistently enforce strict quality control measures from the beginning to the end.
Q6. How long is the delivery time?
A: Delivery typically takes between 7 to 20 working days after payment confirmation.
For urgent orders, we can expedite production in our workshop to meet your deadlines.
Q7. What are your payment terms?
A: 100% T/T in advance, Western Union (For Small Order)
B: 30% T/T upfront and the remaining 70% before shipment
C: 100% Irrevocable LC at sight (For Large Orders)
Q8: Can you produce Deep Drawing Quality (DDQ) materials?
A: Yes, we can. Our materials are ideal for producing stainless steel pots, sinks, bowls, etc. Inform us of your specific use, and we will adjust the mechanical properties accordingly.
Q9: How can I get a sample?
A: We offer FREE samples for your evaluation and testing. If you need a small piece, we may cover the courier cost, depending on the situation.
Q10: Which countries have you exported to?
A: We have proudly exported our stainless steel materials to many countries including Vietnam, Thailand, Turkey, Russia, Morocco, Korea, India, Pakistan, UAE, Ukraine, and more.
Q11: How do I visit your company?
A: Fly to Guangzhou Baiyun International Airport, and we will arrange to pick you up from there.
