Household Plastic Molding Equipment Injection Machine

Product Description

China Servo Injection Molding Machine Explore Ningbo Union Power Machinery Co., Ltd. for top-quality Household Plastic Molding Equipment. We are your reliable supplier for plastic chair molding machines and more.
Product Description:
Product Description Modulus of Capacitance: The position, size, and maximum allowable modulus of capacitance and minimum closure thickness of the injection molding machine guide pillar (Green column).
Nozzle Parameters: Spherical diameter of the nozzle, nozzle aperture, nozzle outer diameter, maximum nozzle extension length, positioning aperture.
Code Mold Parameters: Code mold hole, slot size.
Ejection Mechanism: The position of the ejection point and the diameter of the ejector rod, and if necessary, the ejection force and ejection stroke are also provided.
Mold Opening Stroke and Maximum Opening Distance: Plastic injection machine.
Main Features:
30% higher energy saving than using traditional variable pump.
Stable and smooth movement supported by AC servo motor.
Effective reduction of energy consumption due to reduced oil and cooling water attained by hydraulic system.
High performance European B&R control system.
We are a professional plastic injection molding machine manufacturer for all kinds of plastic products. Clamping force ranges from 70 to 3200Ton, injection weight from 50 to 10000g. We hold CE and ISO certification.
Company Name: Ningbo Union Power Machinery Co., Ltd.

Technical Parameters	Model UP-520T
Injection Unit	A	B	C
Screw diameter (mm)	80	85	90
Shot Volume (cm3)	2135	2410	2702
Injection weight (g)	1943	2194	2495
injection pressure (Mpa)	168	148	132
Screw speed (rmp)	230
Clamping Unit
Clamping force (KN)	5200
Open stroke (mm)	850
Max Mold height (mm)	810
Min Mold height (mm)	330
Space between tie bars(mm)	830x830
Ejector force (KN)	150
Ejector stroke (mm)	240
Others
Pump pressure (Mpa)	16
Motor/driving power (KW)	45(63)
Heating power (KW)	31.5
Machine dimension (M)	8.4x2x2.76
Machine weight (T)	21
Oiltank cubage (L)	900

Injection Molding Machine
Ningbo Union Power Machinery Co., Ltd. - Product Description Injection Molding Machine Are you in need of a reliable injection molding machine supplier? Look no further than Ningbo Union Power Machinery Co., Ltd. Our machines are designed for efficiency and stable performance, tailored to meet your specific product requirements. With a focus on short cycle times and high production output, our machines ensure higher profits for your business.
Key Features:
Customized machine models based on product weight, drawing, and annual quantity
Comprehensive 18-month warranty for components and technical support
Turnkey projects available, including plant design, machine and mold installation, and debugging
Experienced technicians for on-site installation and employee training
Benefits:
Cost-effective solutions with fast lead times for both customized and stock machines
24/7 online support and video technical assistance post-shipment
Spare parts included with every machine, ensuring uninterrupted production
Efficient production processes leading to higher profitability
Contact us today to learn more about our injection molding machines and how we can help streamline your production process.
