Window and Door Making Machine Aluminum Profile Heavy-Duty CNC Machining Center
| US$10,000.00-99,999.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
DSK-CNC-3000DK
Condition
New
Certification
ISO, CE
Automatic Grade
Automatic
CNC or Not
CNC
Voltage
380V
Main Shaft Power
7.5kw
Main Shafte Speed
0-18000r/Min
X Aixs Longitudinal Travel
7000m
Y Aixs Transverse Travel
1300mm
Z Vertical Travel
550mm
X Aixs Speed
0-60mm/Min
Y Aixs Speed
0-30m/Min
Z Aixs Speed
0-20m/Min
Gyrating Range
-90degree0 -90degree
Cutter
12 Tool
Cutting Max Length
165mm
Total Power 13kw
13kw
Clamp Station
8
Weight
1500kgs
Transport Package
Wooden Packaging
Specification
4830*2000*2200
Trademark
Seth
Origin
Jinan
HS Code
8461500090
Production Capacity
500 Units/Month
Packaging & Delivery
Package Size
520.00cm * 240.00cm * 260.00cm
Package Gross Weight
1700.000kg
Product Description
Product Description
Features:
Uses for milling all kinds of holes and slots of aluminum doors, windows
and curtain walls or industrial aluminum profiles, and can perfectly
realize drilling and milling with 3D programming software.
Imported control system, servo motor, high-quality ball screw, linear
guide pair and bearing are adopted to ensure high machining accuracy
of the equipment.
The fixture position can be placed automatically.
Double worktable can process two or two profiles at the same time,
with interactive feeding and non-interference.
With 12-station tool magazine, automatic tool change.
Adopt high-speed motorized spindle imported from Italy, which
can finish machining at any angle within 90, and has high working
efficiency.
The 9-meter extension model can be customized. Detailed Photos
