torque rheometer | HY-4900

Product Description

Product Description
Product DescriptionHY4900 Torque Rheometer is a measuring system for studying the flow, plastcizing, heat and shear stability of polymers. This system consists of a platform and some function units, such as the mixer and extruder. The platform connected with a function unit can measure flow and compounding behaviors, critical processing parameters of temperature, pressure, torque and viscosity of polymers in the laboratory-requiring only small sample volume. This instrument, which is designed to a excellent system with high measuring precision, handling flexibility and testing reproducibility, has been widely applicated in science research, quality control and process experiment. Specification Parameters Motor Schneider imported servo system, 4.08kwReducer Imported from Germany Neugart, 1:15 or 1:20Speed range 0.1~200rpmSpeed accuracy 0.05%F.S.Torque0~230NmTorque accuracy0.1%F.S.Melt pressure range0.1~100MPaMelt pressure accuracy0.5%F.S.Temperature range0~400℃Temperature accuracy ±1℃Temperature channel 5 (4 channels for controlling temperature)Power supply 3phase, AC380V, 50Hz, 30A
