Jacquard Terry Towel Warp Knitting Machine

Product Description

Product Description
The warp knitting towel machine is a tricot warp knitting machine for producing looped fabrics. Its product features are that the loops are rooted on the polyester pillar stitch fabric, which will not snag, and it is not easy to fall apart when cutting. The loops are naturally twisted and twisted. The loop height is uniform, and the cloth surface is soft and flat.
The terry fabric can be designed as single-sided terry, double-sided terry, one side long and one side short terry, horizontal strip terry and block terry, etc. On the latest loop warp knitting machine, change GB1 to jacquard bar to produce jacquard towels.
Terry fabric can be used as shaped towels and bath towels, sofa covers, bathrobes, casual clothes, beach wear, bed sheets, bedspreads, curtains and shoe clips, etc. After the long-terry fabric is sheared and brushed, it can also be made into a cotton elastic.
Compared with the traditional loom terry machines, warp knitting terry machine has a much higher productivity, and the process is more environmentally friendly and resource-efficient.

The advantages of the TS4-TJ terry knitting machine lie in its large productivity, stable working performance, user-friendly operation system, and economical maintenance cost.

Now A-ZEN provides local installation and technical services for warp knitting machines in China, Turkey, Pakistan, Russia, India, and some other places.
Product Specification

1. Working Width/Gauge	186"/E24;
2. Working Speed	50-600rpm (Depends on Yarn and Designs);
3. Bars/Knitting Elements	Individual Needle Bar with Compound Needles, Tongue Needles, and 4 Guide Bars. All Bars and Beds are Made of Carbon-fiber-reinforced Material;
5. Pattern Drive System	EL Drive;
6. Yarn Let-off Device	EBC Yarn Let-off System;
7. Fabric Take-up	Electronic Fabric Take-up System;
8. Batching Device	Electronical Batching Device;
9. Laser Stop Detector and Online Service Program	Equipped;
10. Air Blower Device	Equipped.

Products Application
TS4-EL terry towel machine is capable of producing simply patterned or zigzag microfiber terry towel cloth, making the microfiber terry towel more competitive in markets.

Company Profile
CHANGZHOU A-ZEN TEXTILE TECHNOLOGY CO LTD. is a warp knitting machines and spare parts manufacturer, which locates in Changzhou, China. In the past 15 years, we have already provided nearly 1,000 sets of warp knitting machinery in markets, including Multi-bar Raschel machines, Jacquard Machines, Tricot Machines, Double-Needle Bars Machines, and Warping Machines.
Driven by a responsible attitude, ongoing innovation, and open collaboration, A-ZEN has established a competitive warp knitting technology (WKT) portfolio of end-to-end solutions in warp knitting machinery, spare parts and technology training, and the markets including China, Turkey, India, Egypt, Indonesia, Bangladesh, Brazil, Pakistan, Syria, Iran, Kenya, Thailand, Mexico, and other countries and areas.
Thanks to the sound technology and in-time after-sales service, A-ZEN has won a high reputation from markets, and A-ZEN is committed to enabling the warp knitting future diversified industry, and building a better world.

Manufacturing Factories:

We have four workshops, two of them are warp knitting machines and warping machines workshops, and another two are fabric production mill and spare parts manufacture workshops separately.
Most of our newly developed machines will be used in our fabric knitting factory for a profound test, after which, we will promote into the market.
Spare parts such as compound needle bed, tongue needle bed, needle guide bar, sinker bed, and latch needle bed are produced in our CNC machines, the bars or beds used on Chinese and German warp knitting machines.

Global Exhibition: We attend professional textile machinery exhibitions worldwide, such as ITMA, ITM, ITME, and many others. During the exhibition, we not only display our newly developed technology but also offer economical products to our customers.
It is also a good time to collect customers' feedback and new demand so that we can make better machines for them.
Communication and Cooperation is our theme to participate in all exhibitions.
Customer Training Technical support plays an extreme role in warp knitting machine services. We offer different forms of training, including professional manual books, online guides, video albums, and on-site training.
So far, we have offered on-site training in more than 10 countries and built up our own local service teams in Turkey, India, Pakistan, Indonesia, Iran, and Egypt.
Our in-time & professional technical support gains a high reputation in markets.
