10kw 20kw 30kw off-Grid Solar Inverter Pure Sine Wave Inverter
Basic Info.
Model NO.
NB48-10KDZ
Nature of Source Flow
Passive inverter
Phase
Single
Output Power
>1000W
Certification
CE, ISO9001
Type
DC/AC Inverters
Power Source
Solar Power, Wind Power
Circuit Topologies
Full-Bridge Type
Nature of Wave String
Sine Wave Inverter
Product Name
30kw off Grid Sine Wave Single Phase Inverter
Application
Solar Power System Home
Output Waveform
Pure Sine Wave Output
Display
Display
Efficiency
93%-97% ( High Efficiency )
Output Rated Current
272A / 250A / 136 a /125A
Output Voltage Accuracy
110 VAC / 120 VAC / 220 VAC / 240 VAC± 1%
Output Frequency Accuracy
50Hz / 60Hz ±0.05%
Inverter Efficiency
94%
Transport Package
Wooden Case
Specification
800*600*2260mm 360kg
Trademark
Deming
Origin
China Jinan
HS Code
8504403090
Production Capacity
5000/Year
Product Description
Product DescriptionDetailed Photos
Product Parameters
10KW off grid single phase inverter technical parameters
| Type | NB48-10KDZ | NB96-10KDZ | NB120-10KDZ | NB240-10KDZ | |
| DC input | Input rated voltage | 48 VDC | 96 VDC | 120 VDC | 240 VDC |
| Input rated current | 231 A | 116 A | 93 A | 46 A | |
| Input DC voltage range | 40-62 VDC | 80-124 VDC | 100-155 VDC | 200-310 VDC | |
| AC input | Allow input voltage range | 110 VAC / 120 VAC / 220 VAC / 240 VAC ± 15% VAC | |||
| Input rated current | 91A / 104A / 45.5 A / 42A | ||||
| Bypass transfer time | ≤40 ms(Can be customized ≤4ms version) | ||||
| AC output | Output rated power | 10KW | |||
| Output rated voltage and frequency | 110 VAC / 120 VAC / 220 VAC / 240 VAC,50Hz / 60Hz | ||||
| Output rated current | 91A / 104A / 45.5 A /42A | ||||
| Output voltage accuracy | 110 VAC / 120 VAC / 220 VAC / 240 VAC± 1% | ||||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
| Waveform distortion (THD). | ≤3% (Linear load) | ||||
| Dynamic response time (Load 0←→100%) | 2ms | ||||
| Power factor (PF) | 1 | ||||
| Overload capacity | 120%,5 minutes;200%,3 seconds | ||||
| Crest factor (CF) | 3:1 | ||||
| Inverter efficiency | 94% | ||||
| Working Environment | Dielectric strength | 1500VAC,1minute | |||
| Noise (1m) | ≤50dB | ||||
| Ambient temperature | -20ºC~+60ºC | ||||
| Humidity | 0~90%, No condensation | ||||
| Altitude | <6000m Higher than 2000m rated power should be reduced | ||||
| Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
| Equipped with isolated transformer | Yes | ||||
| Pure Sine Wave | Yes | ||||
| AC Charger | Available, optional | ||||
| Solar Battery Charger | Available, optional | ||||
| Dry Contact | Available. optional | ||||
| Size | 550*480*1200mm | ||||
| Weight | 130kg | ||||
15KW off grid single phase inverter technical parameters
| Type | NB48-15KDZ | NB96-15KDZ | NB120-15KDZ | NB240-15KDZ | |
| DC input | Input rated voltage | 48 VDC | 96 VDC | 120 VDC | 240 VDC |
| Input rated current | 347 A | 174 A | 139 A | 69 A | |
| Input DC voltage range | 40-62 VDC | 80-124 VDC | 100-155 VDC | 200-310 VDC | |
| AC input (AC Bypass) | Allow input voltage range | 110 VAC / 120 VAC / 220 VAC / 240 VAC ± 15% VAC | |||
| Input rated current | 136A / 125A / 68A / 62.5A | ||||
| Bypass transfer time | ≤100 ms(Can be customized ≤4ms version) | ||||
| AC output | Output rated power | 15KW | |||
| Output rated voltage and frequency | 110 VAC / 120 VAC / 220 VAC / 240 VAC,50Hz / 60Hz | ||||
| Output rated current | 136A / 125A / 68A / 62.5A | ||||
| Output voltage accuracy | 110 VAC / 120 VAC / 220 VAC / 240 VAC± 1% | ||||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
| Waveform distortion (THD). | ≤3% (Linear load) | ||||
| Dynamic response time (Load 0←→100%) | 2ms | ||||
| Power factor (PF) | 1 | ||||
| Overload capacity | 120%,5 minutes;200%,3 seconds | ||||
| Crest factor (CF) | 3:1 | ||||
| Inverter efficiency | 94% | ||||
| Working Environment | Dielectric strength | 1500VAC,1 minute | |||
| Noise (1m) | ≤50dB | ||||
| Ambient temperature | -20ºC~+60ºC | ||||
| Humidity | 0~90%, No condensation | ||||
| Altitude | <6000m (Higher than 2000m rated power should be reduced) | ||||
| Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
| Equipped with isolated transformer | Yes | ||||
| Pure Sine Wave | Yes | ||||
| AC Charger | Available, optional | ||||
| Solar Battery Charger | Available, optional | ||||
| Dry Contact | Available. optional | ||||
| Size | 550*480*1200mm | ||||
| Weight | 200kg | ||||
20KW off grid single phase inverter technical parameters
| Type | NB48-20KDZ | NB96-20KDZ | NB120-20KDZ | NB240-20KDZ | |
| DC input | Input rated voltage | 48 VDC | 96 VDC | 120 VDC | 240 VDC |
| Input rated current | 463 A | 231 A | 185 A | 93 A | |
| Input DC voltage range | 40-62 VDC | 80-124 VDC | 100-155 VDC | 200-310 VDC | |
| AC input (AC Bypass) | Allow input voltage range | 110 VAC /120 VAC /220 VAC /240 VAC ± 15% VAC | |||
| Input rated current | 182A / 167A / 91 A / 83A | ||||
| Bypass transfer time | ≤100 ms(Can be customized ≤4ms version) | ||||
| AC output | Output rated power | 20KW | |||
| Output rated voltage and frequency | 110 VAC / 120 VAC / 220 VAC / 240 VAC ,50Hz / 60Hz | ||||
| Output rated current | 182A / 167A / 91 A / 83A | ||||
| Output voltage accuracy | 110 VAC / 120 VAC / 220 VAC / 240 VAC±1% | ||||
| Output frequency accuracy | 50Hz / 60Hz ± 0.05% | ||||
| Waveform distortion (THD). | ≤3% (Linear load) | ||||
| Dynamic response time (Load 0←→100%) | 2ms | ||||
| Power factor (PF) | 1 | ||||
| Overload capacity | 120%,5 minutes;200%,3 seconds | ||||
| Crest factor (CF) | 3:1 | ||||
| Inverter efficiency | 90% | ||||
| Working Environment | Dielectric strength | 1500VAC,1minute | |||
| Noise (1m) | ≤50dB | ||||
| Ambient temperature | -20ºC~+60ºC | ||||
| Humidity | 0~90%, No condensation | ||||
| Altitude | <6000m Higher than 2000m rated power should be reduced | ||||
| Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | ||||
| Equipped with isolated transformer | Yes | ||||
| Pure Sine Wave | Yes | ||||
| AC Charger | Available, optional | ||||
| Solar Battery Charger | Available, optional | ||||
| Dry Contact | Available. optional | ||||
| Size | 610*950*1300mm | ||||
| Weight | 210kg | ||||
| Type | NB120-30KDZ | NB240-30KDZ | NB380-30KDZ | |
| DC input | Input rated voltage | 120 VDC | 240 VDC | 380 VDC |
| Input rated current | 278 A | 139 A | 88 A | |
| Input DC voltage range | 100-155 VDC | 200-310 VDC | 320-496VDC | |
| AC input (AC Bypass) | Allow input voltage range | 110 VAC / 120 VAC / 220 VAC / 240 VAC ± 15% VAC | ||
| Input rated current | 272A / 250A / 136 A /125A | |||
| Bypass transfer time | ≤100 ms(Can be customized ≤4ms version) | |||
| AC output | Output rated power | 30KW | ||
| Output rated voltage and frequency | 110 VAC / 120 VAC / 220 VAC / 240 VAC,50Hz / 60Hz | |||
| Output rated current | 272A / 250A / 136 A /125A | |||
| Output voltage accuracy | 110 VAC / 120 VAC / 220 VAC / 240 VAC± 1% | |||
| Output frequency accuracy | 50Hz / 60Hz ±0.05% | |||
| Waveform distortion (THD). | ≤3% (Linear load) | |||
| Dynamic response time (Load 0←→100%) | 2ms | |||
| Power factor (PF) | 1 | |||
| Overload capacity | 120%,5 minutes;200%,3 seconds | |||
| Crest factor (CF) | 3:1 | |||
| Inverter efficiency | 94% | |||
| Working Environment | Dielectric strength | 1500VAC,1minute | ||
| Noise (1m) | ≤50dB | |||
| Ambient temperature | -20ºC~+60ºC | |||
| Humidity | 0~90%, No condensation | |||
| Altitude | <6000m Higher than 2000m rated power should be reduced | |||
| Production function | Input reverse protection, input under-voltage protection, output overload protection, output short circuit protection, thermal protection | |||
| Equipped with isolated transformer | Yes | |||
| Pure Sine Wave | Yes | |||
| AC Charger | Available, optional | |||
| Solar Battery Charger | Available, optional | |||
| Dry Contact | Available. Optional | |||
| Size(mm) | 800*600*2260mm | |||
| Weight(kg) | 360kg | |||
