Sp63CE Spi Rgbcct Addressable LED Magic Color Strip Light Controller DC5-24V Smart Bluetooth Music Pixel Dimmer RF Remote Panel

Product Description

SP63CE SPI RGBCCT Addressable LED Magic Color Strip Light Controller DC5-24V Smart Bluetooth Music Pixel Dimmer RF Remote Panel Product Description SP63CE ControllerFor RGB LED StripSupply voltage: DC5-24VOperating temperature: -20-60°COutput mode: 4pin RGBMaximum load current: <6AInput power: 5V<30W, 12V<72W, 24V<288WStatic power consumption: <1W
Product Features
1. Support mobile APP control;2. Support the automatic connection of the device when the APP starts and the automatic reconnection of the device after disconnection;3. Support group control of multiple devices;4. Support two music collection modes: mobile phone microphone and player streaming;5. Supports functions such as modifying device name, calibrating RGB channel sequence, timer, etc.;6. Supports common single-line LED driver ICs on the market, and supports driving 600 pixels;7. Built-in 142 dynamic modes, support dynamic mode effect length adjustment, dynamic mode collection, and dynamic mode and collection mode can be cycled independently;8. Built-in 18 music modes,Support music mode effect length adjustment, sensitivity adjustment, effect color self-selection and music mode cycle;9. DC5~24V wide voltage input, the power supply has anti-reverse connection function;10. The function of saving setting parameters when power off.Use tutorial
1. Download "BanlanX" APP from Apple App Store or Google Play Store2. Turn on the bluetooth of the mobile phone and the position switch (make sure that no other device is connected to the bluetooth), and power on the lamp3. Open the "BanlanX" App, it will automatically connect to the controller. Connections will show the number of connectionsIf the device cannot be connected
1. Check whether the lamp is powered on normally2. Whether the Bluetooth of the mobile phone is turned on3. Whether the Bluetooth of the mobile phone is connected by other devices4. Is there any other mobile phone connected, if so, please disconnectNoteThe signal receiver has the (+) symbol in the upper right corner of the text to align with the pins of the upper left (black) arrow at the plug interface. If the plug is reversed, the light strip will not light up
Product Parameters
Key attributes Industry-specific attributes Warranty(Year) 1-Year
Type Remote Control
Max. Load Power 288W
Other attributes Place of Origin Guangdong, China
Lighting solutions service Lighting and circuitry design, Onsite metering, Project Installation
Product Weight(kg) 0.09
Brand Name Lebeisenf
Connection Mode Common Anode
Product name SPI RGB + 2CH PWM LED controller
Application Constant voltage SPI RGB+2CH PWM LED
Function Smart Home Control
Voltage DC5V-24V
Keyword Smart Dimmer Module
Features Easy Installation
Certificates CE FCC ROHS
Output signal PWM+SPI (TTL) Digital Signal
IC Count ≤ 600 pixels
Material Plastic
Packaging and delivery Packaging Details Standard export packaging
(Dear friends;
The company provides OEM/ODM one-stop support services, welcome your consultation)
Selling Units: Single item
Single package size: 20X10X5 cm
Single gross weight: 0.110 kg
Show less Lead time

Quantity (pieces)	1 - 20	> 20
Lead time (days)	7	To be negotiated
