Basic Info.
Automatic Grade
Semi-Automatic
Packaging Material
Plastic
Application
Cosmetics, Cleaning, Detergent, Drinks, Oil, Dairy Products, Skin Care Products, Hair Care Products, Vegetable, Fruit, Fish, Meat, Snack, Rice, Flour, Seasoning, Commodity, Food
Usage
Outpacking, Inner Packing
Packaging Material Mechanical Properties
Flexible Container Sealing
Voltage
AC 220/50 110/60 (V/Hz)
Printing Heating Power
50X2 W
Temperature Range
0-300 Degrees Celsius
Printing Type
Color Ribbon
Distance From Sealing Center to Conveyor
10-40 mm
Distance From Base Plate to Conveyor
85-115 mm
Conveyor Table Size (L X W)
1065X205 mm
Max. Conveyor Loading for Single Package
>=1 Kg
Overall Conveyor Loading
>=3 Kg
External Dimensions (L x W x H)
1065X460X500 mm
Transport Package
Wooden Case
Specification
119*59*63cm
Origin
Zhejiang, China (Mainland)
Production Capacity
5, 000 PCS/Year
Packaging & Delivery
Package Size
119.00cm * 59.00cm * 63.00cm
Package Gross Weight
67.000kg
Product Description
Product Description Hualian Color Ribbon Printing Continuous Band Sealer
Novel design idea and advanced manufacturing technology are adopted to make the structure of the machine more reasonable and perfect. Apart from the functions of sealing and printing, model FRSC-1010III has the function of air suction.
FRS-1010 series is available in four models: horizontal model (FRS-1010I), vertical model (FRS-1010II), floor-standing model (FRS-1010III), and floor-standing model with the function of air suction (FRSC-1010III).
The machine can seal all kinds of heat-sealable materials, which adopts a constant temperature control system and step-less speed adjusting transmission mechanism. The machine works with a solid-ink coder to print the colored labels while sealing. The coder is able to print at high speed with instant dry and highly legible letters that have good adhesion properties. The printing wheel in the machine can be used for both R arrange and T arrange of types. For types in R arrange, the machine can print two lines in font size two (18PT) or three lines in font size five (10.5PT).
Features:
√Reliable performance
√Simple operation
√Convenient maintenance
√Wide range of application
√Constant temperature control system
√Stepless speed regulation
√With printing function
√Various color ribbons are selectable
√Counting device is optional
Application:
1. FRS-1010 series plastic film bag continuous sealing machine is suitable for sealing all kinds of heat-sealed packages continuously. Such as PE bag, accordion bag, aluminum foil bag, kraft paper bag, electrostatic bag, Yin-Yang bag.
2. It widely use in the food, pharmaceutical industry, chemical industry, agriculture, lubricating oil, and other industries.
3. To use in the place where there is a restriction on space, such as small factory, monopolization shop, and workshop, etc.
