Basic Info.
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.1~0.5m³
Max. Digging Height
3700mm
Max. Dumping Height
2290mm
Max. Digging Depth
2450mm
Max. Vertical Digging Depth
2160mm
Max. Digging Radius
4370mm
Max. Lifting Height of Blade
240mm
Max. Cutting Depth of Blade
310mm
Boom Swing Angle(Left)
75°
Boom Swing Angle(Right)
45°
Transport Package
4170mm*1300mm*2280mm
Packaging & Delivery
Package Size
417.00cm * 130.00cm * 228.00cm
Package Gross Weight
3000.000kg
Product Description
Company Profile
ABOUT US
Shandong Hightop Group is a large-scale engineering construction machinery and equipment manufacturing
group integrating scientific research, production and service. Its headquarter is located in Jining City, Shandong
Province, covering an area of about 133,000 sq meters and a total of more than 300 employees.Hightop group
is "Specialization, Refinement, Distinctive, Novelty" honorary enterprises of Jining city, and has introduced as a
key project enterprise by goverment of The Economic and Technological Development administrative district Our Advantages
Manufacturing Technique
FAQ
How Our High-Quality excavator skid loader Benefit You? For Consumers:
"Our Excavator,Skid loader offer affordability, customizability, and a diverse selection of models, whether
model,to perfectly match your needs."
For Suppliers:
"Our excavator,skid loader redefine industry standards with innovative features, durability, and exceptional support. Maximize
profitability with competitive pricing and lucrative incentives. Additionally, we provide top-notch after-sales services,including
equipment installation, commissioning, and maintenance, all aimed at safeguarding our customers' interests. Contact us to become a
dealer partner and unlock boundless opportunities in the construction industry. " Product Parameters
Machine Size |
Overall dimension (L*W*H) | 4170mm*1300mm*2280mm |
Axle base(Track length on ground) | 1230mm |
Track gauge | 1070mm |
Min.Ground clearance | 230mm |
Swing radius at tail | 1180mm |
Track System |
Maximum Travel speed | 3.5km/h |
Width of track shoe | 230mm |
Number of track shoe per side | 38pcs |
Number of upper roller per side | 0 |
Number of bottom roller per side | 4 |
Engine |
Emission Standard | Euro5 |
Engine Model | China Laidong |
Power/Rotation speed | 22.1kw,2300rpm |
Number of cylinder | 3 |
Performance Parameter |
Standard bucket capacity | 0.1mm³ |
Swing speed | 12rpm |
Max. Grade ability | 30° |
Max. Bucket digging force | 15.3KN |
Max. Arm digging force | 10.5KN |
Hydraulic system pressure | 18Mpa |
Machine weight | 3000kg |
Arm length | 1000mm |
Working Range |
Max. Digging height | 3700mm |
Max. Dumping height | 2290mm |
Max. Digging depth | 2450mm |
Max. Vertical digging depth | 2160mm |
Max. Digging radius | 4370mm |
Min .swing radius | 2020mm |
Max. Lifting height of blade | 240mm |
Max. Cutting depth of blade | 310mm |
Boom swing angle(Left) | 75° |
Boom swing angle(Right) | 45° |
