Split Solar Flat Plate Panel Pool Solar Collector

Product Description

Flat Plate High Pressure Split Blue Absorber Solar Collector
Specification of whole system:

Flat-plate collectors are the most common solar collectors for use in solar water-heating systems in homes and in solar space heating. A flat-plate collector consists basically of an insulated metal box with a glass or plastic cover (the glazing) and a dark-colored absorber plate. Solar radiation is absorbed by the absorber plate and transferred to a fluid that circulates through the collector in tubes. In an air-based collector the circulating fluid is air, whereas in a liquid-based collector it is usually water.
Flat-plate collectors heat the circulating fluid to a temperature considerably less than that of the boiling point of water and are best suited to applications where the demand temperature is 30-70°C (86-158°F) and/or for applications that require heat during the winter months.
Flat collectors can be mounted in a variety of ways, depending on the type of building, application, and size of collector. Options include mounting on a roof, in the roof itself, or free-standing.

Model	IPRE E-A	IPRE E-B	IPRE E-C
Dimensions(W*L*H)	2000*1060*80mm	2000*1060*80mm	2000*1060*80mm
Absorber area()	2	2	2
Absorber area()	1.8	1.8	1.8
Conversion factor %	77.3	79.8	72.8
Loss coefficient a1w/K	3.9	3.65	4.33
Loss coefficient a2w/K	0.0052	0.0065	0.021
Fluid content L	2.22	2.22	3
Maximum operating pressure Mpa	1	1	0.3
Temperature of operation	(-)35~150	(-)35~150	(-)35~150
Net weight KG	33	33	32
Core	All copper,ultrasonic welding,Copper and aluminum composite technology
Coating	Black chrome	Selective titanium	Positive electrode oxidation
Absorptance	≥95%±2%
Emittance	≤10%±2%	≤4%±2%	≤20%±2%
Absorber	Copper T2,δ=0.15mm,aluminum,δ=0.15mm
Header pipe	Copper T2,22*0.7*1060mm,2pcs
Riser pipe	Copper T2,Φ10*0.5mm,8pcs,Copper and aluminum,Φ14*0.45mm,7pcs
Glass cover	Normal glass:4mm/tempered glass:4mm,rhombic tempered glass:4mm/low iron rhombic tempered glass:3.2mm
Dimensions of glass sheet	1988*988mm
Transmittance of glass	87%~91%
Frame	Aluminum,δ=0.9mm
Color of frame	Champagne,bronze-coloured,white
Insulation material	Glass wool,PE Foam/glass wool,high dense polyurethane foam
Insulation thickness	40mm
Back sheet	Galvanized plate:0.3mm/embossed aluminum:0.3mm
Cover sealing material	Metal/EPDM+metal
Packing	carton
Packing dimension	2020*1100*80

Automatic Workshop
1.Modern workshops have advanced production lines and professional knowledge of assembly.
2.Flow card to record each details carefully.
3.100% self-inspection before packing.
Advantages
1.Economic and practical products from Sunlight , reliable performance.
2.Choose Sunlight, choose a rest assured.
3.Advanced production lines and test rooms.
4.Perfect QCP.(Quality control plans)
Application: car, truck, bus, cooler room
Packaging & Shipping
Strong packaging to ensure safety during transportation.
Export wooden box packaging for products.
FAQ
Q1.Can I have a sample for testing?
A: Yes,of courses we can supply the sample for you !
Q2.Can I add my logo on the water tank?
A:Yes,OEM and ODM are available for us.But you should send us LOGO image.
Q3. How can i get the after-service?
A:We will send you the spare parts by free if the problems caused by us.If it is the men-made problems,we also send the spare parts,but you should pay.
Q4.Do you have inspection before delivery?
A:100% self-inspection before packing
Q5.Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.Here is our factory address:No. 5 Shengda Road, Konggang Industrial Park ,Luoxi Town, Xinbei District, Changzhou City, Jiangsu Province China.
