Factory Wholesale Industrial Food Processing Autoclave Jar Sterilizer Retort Machine

Product Description

Full automatical water spray/steam/electric retort machine is the universal type retort which can be used to process any type of products in any type of containers. The operational and maintenance cost is less which make it welcomed by most of the customers. In steam retort, steam is directly injected into the retort. Since the steam is freely allowed to pass through the entire chamber, all the products get temperature, cooking effect and sterilization effect uniformly. The steam retort is suitable for all kinds of high-temperature resistant packaging material.
Characteristics:
1. Uniform temperature distribution:In the process of heating and sterilization, the water is continuously sprayed from nozzles adopted high speed spraying, so that the temperature in the pot is kept stable and the sterilization effect is improved.
2. Direct heating and indirect cooling, and prevent the second pollution. Sterilizing and cooling processes use the same water. Circulating water is directly heated by steam diffusion tube in the heating process. Under 0.5MPapressure, it only takes 6-12min to rise the temperature from 20 DEG to 121 DEG. Continuous cooling by heating exchanger is isolated from the products, preventing the second pollution in the cooling effectively.
3. Full-automatic control system:
a. Siemens Touch Screen
b. No-paper recorder
c. Imported Automatic Valves
d. Many sterilization techniques in memory for your choice. At most could save 250sterilization formula.
4. Pressure control system independently, suitable for gas packaging sterilization: Pressure control
error is within 0.005Mpa. Pressure control system can correct and balance the pressure inside of the pot and packing automatically, not damaging the packing or the contents.
Water spray autoclave/retort/sterilization pot
Model No. Outside Measurement(mm) Inner Diameter(mm) Vessel Length(mm) Capacity(m³) Thickness of Autoclave(m) Max Working PRE.(Mpa) Max Working TEP.(ºC)
5. Heating and cooling in stages can reduce the temperature difference between the surface and the center of the food in protection of fragile food and glass bottles.
Technical parameter

Model NO.	Diameter	Length	Capacity	Thickness	Design Temp	Design Pres
ETR0918	900mm	1800mm	1.14m³	4mm	121C	0.35MPa
ETR1020	1000mm	2000mm	1.57m³	4mm	121C	0.35MPa
ETR1222	1200mm	2200mm	2.48m³	5mm	121C	0.35MPa
ETR1430	1400mm	3000mm	4.61m³	5mm	121C	0.35MPa

Can be customized according to needs Application
For high temperature sterilization of fruits, vegetables, meat, fish, convenience foods, etc.
Packaging Container: PP bottles, HDPE bottles
Metal Containers: tin cans
Aluminum cans plastic containers
Soft bag packaging: aluminum foil bag, transparent bag, vacuum bag, cooking bag and so on
Scientific experiments show that the best sterilization temperature of the tide type brine food is 121 DEG, the best sterilization time is 12min, which can not only ensure the good sterilization effect, but also keep the flavor of the brine.
Mainly applicable to canned food (such as meat, fish, eggs, vegetables etc.), protein beverage (milk, soy milk, coconut milk, peanut milk, walnut milk, almond milk etc.), hard cans (tin cans, glass bottles, cans etc.) and various kinds of soft packaged food. Packaging & Shipping
We will deliver your goods by LCL/20'FCL/40'FCL depending on your order.
Before delivery, our professional technician will do trial run for each product to check until everything is functional, you also can come to our factory and test our machine together with us.
When loading, our workers will fix the retorts tightly with wire rope so that the retorts can't move in the container

We have a professional working team that can design for you, to ensure that you buy the best quality and fittest machine in least money.
After sale, we provide one-year warranty to make sure that your machine runs functionally and consistently. We also provide lifelong services and spare parts for the machine.
FAQ
1. Are you manufacture or trading company?
We are manufacture; our factory is located in Qingdao.

2. What is max diameter we can do for you?
The maximum diameter which our company can make is 4.5m. And the length is up to your requirements.

3. How much capacity can you treat per tank at a time?
It is up to the diameter and length of the equipment designed by your demands.

4. Is the control system manual, semi-automatic or full-automatic?
Our control system is full-automatic operation system.

5. Can we install the equipment by ourselves?
Of course, we will provide you with detailed installation information.
