ISO Automatic Transmission Conveyor Roller/Idler Shaft Double End Holes Turning Lathe Making Machine Conveyor Roller Boring Manufacturing Machine for Mining

Product Description

1, Machine features:
This machine tool is a special machine tool designed to process the ends of steel pipe of belt conveyor. It is suitable for all kinds of rollers produced at home and abroad (cast iron or punching bearing seat).The machine adopts mechanical fast clamping device, reliable clamping, simple and convenient adjustment of clamping force, hydraulic drive of cutter feed, adjustable speed without electrode, and hydraulic synchronous loop of right and left two feed cylinders, which can feed at the same time and return the cutter at the same time.
The radial feed adopts manual operation, which can be adjusted precisely according to the machining requirements. It is equipped with a hydraulic automatic tool mechanism, which can automatically let the cutter when it is fed to a predetermined position. Avoid scratching the machined surface. The control system based on the imported programmable controller (PLC) is used for electrical control.
The equipment has the advantages of wide application, high reliability and high working efficiency. It is especially suitable for the processing and production of batch rollers.
2, Technical specification:

project	parameter
model	TC-160*2200
Machine tool spindle center height	900mm
Outer diameter of processed steel pipe	Ф76-159mm
Machined steel pipe length	200-2200mm
Depth of both ends of processing	0-70mm
Sliding speed of sliding seat	2m/min
main shaft speed	500r/min
feed rate	Hydraulic stepless speed regulation
cutting depth	0-3mm
Tool holder radial feed scale value per lattice	0.05mm
Accuracy of Radial tool Repeating-positioning of tool holder	0.05mm
Main drive motor	4kw 1450r/min
Workpiece clamp motor	1.5kw 1450r/min
Working pressure of hydraulic system	2.5-4Mpa
rate of flow	0-25L/min
contour size of the unit(s)	4500×1000×1200mm
weight	2500Kg
