Hot sale Universal Milling Machine good price from China
| US$4,500.00-8,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
1370*320mm table size
Structure
Ram
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Integral
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
High Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
process
metallic or non-medallic materials
Transport Package
Wood Pallet
Specification
1900*1750*2230
Trademark
Hercules
Origin
China
HS Code
8459699000
Production Capacity
20000/Year
Product Description
Feature:This milling machine is a kind of universal light duty metal processing machine,
two functions of vertical and horizontal mills, it could proceed on medium or small parts of the plane, inclined plane, groove and spline, etc..
Widely used in mechanical processing, mold, equipment, instrumentation and other industries.
| Specification | ||
| Table size | mm | 1370*320 |
| Table travel X/Y/Z | mm | 820/300/400 |
| Spindle taper | ISO40(H,V) | |
| Max turning angle of working table | deg | ±45 |
| Tilt angle for milling head | deg | left and right ±45 |
| T-slot number/width | 3/14mm | |
| Arbor dia. | mm | 27 |
| Disance from horizontal spindle center to table | mm | 75-475 |
| Disance from spindle nose to table | mm | 160-560 |
| Distance from spindle axis to ram surface | mm | 200 |
| Spindle speed range | r/min | 65-4660(V) 35-1500(H) |
| Feeding range of longitudinal, cross travel | mm/min | 30-830 |
| Auto-feeding of Z-axis | mm/min | 23-625 |
| mm/min | 1335 | |
| mm/min | 1000 | |
| Horse power for main motor | kW | 3.7(V) 3.0(H) |
| Overall dimensions | mm | 1900*1750*2230 |
| N.W/G.W | KGS | 1950/2250 |
Pictures for reference only:
