550 MPa Metal Roofing Sheet Making Steel Roof Panel Corrugated Roll Forming Machine

Product Description

550 Mpa Metal Roofing Sheet Making Steel Roof Panel Corrugated Roll Forming Machine The roofing panel machines can produce various of steel roof and wall panel, it is a new building materials ,the products are widely used as the roof and wall of factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre, etc. It has many advantages, such as easy installation, short building period , beauty, light weight but high strength.

1. Processing flow diagram of machine:
Decoiler→ Feeding →Roll forming →Measure length →Hydraulic cutting →Output table
2. Profile Drawings for Reference:
3. Technical parameters for 550 Mpa Metal Roofing Sheet Making Steel Roof Panel Corrugated Roll Forming Machine : A. General

Suitable Material	HRB60 or equivalent
Material Thickness	0.2-0.6 mm
Dimension	About 7.2*1.3*1.1m(L*W*H) , as per the drawing
Length of the Sheet	You can set the length according to your need. It is controlled by PLC which can ensure the accuracy of ±1mm.
Cutting	Automatically stop and cutting when it comes to the set length.

B. Components Details

Roller Material	High grade 45# steel. Hard chrome plating, 0.05mm.
Main Frame	350# steel. More stable and no shaking.
Middle Plate	16mm. We use thicker plates to ensure stability of our products.
Forming Steps	11-16, according to the drawing.
Shaft Material	Φ70 mm, high grade 45# steel.
	Treating process: tempering- finish turning, high rigidity, hard to deform.
Cutting Blade Material	Cr12, hardness HRC60-62.
	Treating process: heat treatment- plane abrasion- wire electrode cutting.

C. Electric Components

Suitable Power	380V, 50 Hz, 3 phase or according to your need.
Screen	7 inch touch screen, easy to operate.
PLC	Delta DVP 14ES
	well-adapted to various conditions, such as moisture, electromagnetic disturbance.
Frequency Converter	Delta VFD-M. It has the advantage of slowing down before cutting, to ensure the length accuracy (±1mm, far better than industrial standard ±3mm).
Length Measurement Device	Omron, made in Japan.
	It features with high accuracy and stability.

4. Guarantee:
1) Engineer will give free training lessons to labors in buyer's factory.
2) The Buyer will buy the round-trip air ticket for Engineer if visa application is approved. The buyer is also responsible to bear expenses generated, e.g. visa formalities, meals, accommodation and allowance of USD100 per day for engineer.
3) During this guarantee period, we will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, we will provide the buyer spare parts at cost price.
4). We will charge the buyer cost price of spare parts beyond one year and provide long-term technical guide.
