Forged Stainless Steel Thread Flange (YZF-M016)

Product Description

Forged Stainless Steel Thread Flange (YZF-M016)

Size	1/2' ' (DN15) to 48' ' (DN1200)
Standard	ASME/ANSI, API, DIN, GOST, BS, AS, JIS, JPI, UNI, SABS, etc.
Material	Carbon Steel: A105(N) C22.8 ST-37.2 S400 S440 SQ235(CS20#) A106B A53 Q345 Stainless Steel: 304, 304L, 316, 316L, A350 LF2, 321, 347, 347H Alloy Steel: ASTM A182 F1, F5a, F9, F11, F12, F22, F91
Pressure	Class150, 300, 600, 900, 1500 and 2500 PN6, PN10, PN16, PN25, PN40 and PN64 JIS 5K, 10K, 16K and 20K
Type	Slip-On, Welding Neck, Blind, Socket Welding, Threaded, Lap Joint, Plate, etc.
Facing	RF, FF, FM, MFM, TG, RJ, etc.
Finish	Transparent oil, Rust-proof oil, Hot galvanizing
Connection	Butt Weld & Socket Weld & Thread
Marking	Standard or as customer' s need
Inspection	In-house or the third party
Application	Chemical industry, Petroleum industry, Construction industry, and so on
Delivery Time	Usually within 30 days after we have confirmed your order
Packing	Wooden cases or wooden pallets or as per customer' s requirement

Types' Specification
Threaded
1. Used where welding would would be hazardous
2. Designed for low-pressure and non-cyclic applications
3. Bore is threaded to match pipe thread
4. Tapered to seal pipe and flanges
Slip-on
1. Not normally used in high-stress applications due to low hub and weld attachment
2. Silps over outside of pipe
3. Inside of flange welded at hub and end of pipe
Socket welding
1. For small-diameter chemical processes, hydraulic and stream distribution lines
2. Similar to slip-on flange
3. Counter bore matches pipe bore, allowing unrestricted flow
4. Counter bore from hub side fits pipe's outer diameter - can insert pipe in socket with fillet weld at hub
Lap joint
1. Used where bolt alignment or access for cleaning is required
2. Similar to slip-on flange when used with lap joint stub end
3. Radius at intersection of flange face and bore to match lap joint stub end
Blind
1. Used to close ends of piping
2. Has no bore
3.Permits access to sealed lines
Welding neck
1. Preferred for high-pressure, subzero or elevated temperature
2. Hub is tapered and bored to match pipe's inside diameter so flow is not restricted, preventing turbulence and reducing erosion
3. Easily radiographed and provides excellent stress distribution
Other flanges
Orifice, Expander, Reducing, Lightweight, Studding Outlets, Long Weld Necks,Metric, Navy Drawings, Customer Drawings
Products Show:
Please don't hesitate to click "Contact Now" to get more information about the products and we will do our best for you.Thank you so much!
Our Workshop:
Packing:
Company Information:
1.Professional flange manufacturer, we can manufacture many kinds of flanges with the standard of ASME/ANSI/DIN/JIS/BS, etc.
2.The spirit of our company: Scientific Development, Constant Progress, Harmonious Cooperation, Golden Integrity.
3.The principle of operation: Coordinate, Development, Mutual Benefit, Common prosperity, Customer First.
4.The attitude of work: Work together, Enjoy Together, Progress Together, Develop Together.
5.Export-oriented factory. Export to North America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America as well as other regions.
Our Advantages:
1.Professional manufactory.
2.Trial orders are acceptable.
3.Flexible and convenient logistic service.
4.Competitive price.
5.100% testing,ensuring the mechanical properties
6.Professional testing.
FAQ:
Q1: Are you trading company or manufacturer?
We, 3S INTERNATIONAL COMPANY LTD. CO., is a combination of production and trade, industry integration business.
Q2: What's your payment terms?
We recommend our customer different terms of payment based on different order amount. Paypal, Western Union, T/T, LC are all acceptable.
Q3: Can we require you to print our trademark on your product?
Yes, we're the professional manufacturer. And the OEM service is available.
Q4: Can you provide us with some samples for testing?
A: Of course, we can offer you samples.You only need to bear the freight and the samples expense can be negotiated.
Q5: How about your service?
A: We have pre-sale service, in-sale service and after-sale service. As "Customer First" is the most important principle of company operation.
If any problems not in the above-mentioned answers, you can contact us directly. We will help you to solve the problem with carefulness and patience.
