Zinc Rod Zinc Bar High Pure, vacuum coating, film coating

Product Description

The products are of high purity with low contents of impurity Fe and the film can effectively prevent from being broken through.
Widely used in vacuum coating and other purposes.
The product conforms to the requirements of EU RoHS, REACH, and relevant domestic laws and regulations for environmental protection.
Product code:DMZT, DMZB
Chemical composition:

Item	Main elements (%)		Impurities (≤)%
	Zn ≥	Al ≤	Pb	Fe	Cd	Cu	Sn	Al	∑
DMZT	99.99		0.004	0.008	0.002	0.001	0.001	0.001	0.01
DMZB	99.99		0.004	0.008	0.002	0.001	0.001	0.001	0.01
DMZT 2	99.99	0.003	0.004	0.008	0.002	0.001	0.001	0.001	0.01

Mechanical characteristics:

Item	SPECIFIC GRAVITY	MELTING RANGE
DMZT	7.13±0.1g/cm3	419.5ºC±1ºC
DMZB
DMZT 2

Size: 295mm*20mm*13mm ; dia12mm*330mm

ITEM	LENGTH	WIDTH	HEIGHT	DIAMETER
DMZT	295±5	20±3	13±3	/
DMZT 2	295±5	20±3	13±3	/
DMZB	160±5	/	/	12±0.5
	295±5
	350±5

Customized label, packing, OEM service
Packing: 15-25kgs/cartons 1000kgs/wooden cases/Pallet.
To order confirm the purity, We import the zinc ingot for Japan. Building chemical analysis laboratory, oil analysis laboratory, Spectral analysis laboratory, Strict control of production materials, and strictly monitoring the production process. We are looking forward to your cooperation!
