Strong Force Hydraulic Hose Crimper Crimping Machine Available for Mass Production

Product Description

Technical Data Of Hydraulic Hose Crimping Machine KM-91C-6

Crimp range:	1/8"-2" 4SP
Standard voltage&motor:	380V/3kW
Optional voltage&motor	Your voltage is available
Capacity Of Oil Pump	14.5L/min
Hydraulc Oil	Winter: YB-N32; Summer: YB-N46
Volume Of Oil Tank	65L
Opening without dies	φ122mm
Opening	min28mm
No.of standard die	10 sets
Systematic Pressure	30Mpa
Weight	310kg

Advantages Of Hydraulic Hose Crimping Machine KM-91C-6 :
1)Microcomputer control, accuracy and reliability;
2).Crimp capacity can be precisely controlled, repeat precision of 0.01mm;
3).Back reseting hydro-cylinder, can be easily operated;
4).Increasing the opening, and good passing performance;
5).Added with base-protective resin gasket to not damage the working surface;
6).Function: manual, semi-automatic and automatic;
7).Big swaging force, can easily crimp 2 inch 6 wires hose.
Applications Of Hydraulic Hose Crimping Machine KM-91C-6:
1).Suitable for high precision pressing of low and high pressure hose diameter, starting from 1/8 inch to 2 inch internal hose pipe.
2).Used rubber hose to transmit hydraulic pressure as there working power.
3).Used in Building Construction, Petroleum Industry, Chemical Industry, Car and motor Industry.
Hydraulic hose crimping machine why not choose kangmai ?
1. kangmai hose crimping machine CE& ISO PATENT Approved and SGS Audited.
2. The fitting and hoses crimped by kangmai machine never leak or broken. The reason like below:
(a)The machine head is processed by CNC machine,roundness and taper is within 0.1mm.
(b)The machine die base and dies adopt special die steel and process by advanced craft, the hardness is above 55 HRC. The die hardness is enough so that the die life is very long and easy to crimping high pressure hydraulic hose, 4SP even 6SP.
(c) The technical of machine head is forging or casting. Casting is cheap but has small hole on machine head. The piston will divide from casting machine head.
