Basic Info.
Certification
CE, ISO, GOST, SONCAP, CCC, API
Mixing Drum Shape
Circular Groove
Operating type
Cycle Operating
Transport Package
Export Standard Package
Specification
1600*460*950mm
Production Capacity
20set/Month
Product Description
ZRJ series Vacuum Homogenizing Emulsifying Machine
Instruction and features:
Application:
The equipment is suitable for emulsification of the pharmaceutical. Cosmetic, fine chemical products, especially the material having high matrix viscosity and solid content. Such as cosmetic, cream, ointment, detergent, salad, sauce,lotion, shampoo, toothpaste and so on
Structure Drawing:
Structure:
this homogenizer include main pot, water and oil pot, vacuum system, lift system, temperature system, control system and so on
Principle:
First put the raw material which can dissolved into water into water pot, then heat it , and mix it
Second: put the raw material which can dissolved into oil to oil pot, heat it and mix it,
Then suck both of the raw material into main pot, to homogenize the two material by homogenizer
Character:
Control by computer touch-screen, integrated operation, with beautiful generous;
Work continuously large quantity, circulating homogeneous discharging, especially suitable for single products continuous production
Easy operation, perfect homogeneous emulsification
Capacity : 100-2000L
Helical ribbon mixing, internal external circulating homogenization.
Product Prameters:
Model | Volume | Emulsify | mixer | Outside dimension |
Kw | r/min | Kw | r/min | L | W | H | M H |
ZRJ-30 | 30L | 1.5 | 0-3500 | 0.75 | 0-70 | 1500 | 800 | 1500 | 2050 |
ZRJ-50 | 50L | 3 | 0-3500 | 0.75 | 0-70 | 2750 | 2100 | 1900 | 2600 |
ZRJ-100 | 100L | 3 | 0-3500 | 1.5 | 0-70 | 2800 | 2150 | 2100 | 2800 |
ZRJ-150 | 150L | 4 | 0-3500 | 1.5 | 0-70 | 2850 | 2150 | 2150 | 2900 |
ZRJ-200 | 200L | 4 | 0-3500 | 1.5 | 0-70 | 3000 | 2200 | 2200 | 3100 |
ZRJ-350 | 350L | 5.5 | 0-3500 | 2.2 | 0-70 | 3650 | 2650 | 2550 | 3600 |
ZRJ-500 | 500L | 7.5 | 0-3500 | 2.2 | 0-50 | 3800 | 2800 | 2700 | 3950 |
ZRJ-750 | 750L | 11 | 0-3500 | 3.7 | 0-50 | 3900 | 3900 | 2900 | 4400 |
ZRJ-1000 | 1000L | 11 | 0-3500 | 3.7 | 0-50 | 3900 | 3400 | 3150 | 4550 |
ZRJ-2000 | 2000L | 22 | 0-3500 | 7.5 | 0-50 | 4850 | 4300 | 3600 | 4800 |
