Mobile LPG Propane Gas Cylinder Delivery Storage Tank Station
| US$25,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
23
Function
Storage Pressure Vessel, Separation Pressure Vessel, Heat Pressure Vessel, Reaction Pressure Vessel
Application
Mixture
Material
Carbon Steel
Pressure
p≥100.0MPa
Storage Medium
Moncombustible/Nontoxic
Pressure Level
Low Pressure (0.1MPa≤p<1.6MPa)
Condition
New
Usage
Transport Cook Gas
Capacity
52cbm
Product Name
LPG Propane Gas Storage Tank
Transport Package
Naked or Waxed Before Shipment
Specification
2ton, 5tons, 10t, 20t, 25t, 30t, 40ton, 50t, 60ton
Trademark
clw group
Origin
China
HS Code
7301100000
Production Capacity
500 Unit/Units Per Month
Product Description
Mobile LPG Propane Gas Cylinder Delivery Storage Tank StationLPG transport tank semi-trailer can be modified and designed according to the needs of customers, It is used for transporting LPG gas.
Liquefied petroleum gas (LPG) tank trailer include LPG tank body (made of Q345R steel plate), axle, tire, support leg, traction pin, double outlet double valve box (pressure gauge, thermometer, tight cut valve, ball valve), iron anti-wave plate, safety valve, level gauge, fire-extinguishing appliance, toolbox, anti-static tape, spare tire frame, plastic tire fender, etc.
Tank Material:Q345R
Diameter :2700mm
Shell thickness:14mm
End plate thickness:16mm
Size(L*W*H):10962*2728*3318MM
Standard accessories:Safely valve , Stop valve , Magnetic plate level gauge , Pressure gauge , Thermometer .
Description:
| Tank Essential Information | |
| Volume of Tank | 52 CBM (52,000Liters) |
| Overall Dimensions(L*W*H) | 12840*2480*3800mm |
| Filling Weight | 20832 kg |
| Tare Weight | 15300 kg |
| Total Weight | 36132 kg |
| Wheelbase | 6800+1310+1310mm |
| Shell of tank | |
| Products | Liquefied petroleum Gas(propane) |
| Fluid Property | Flammable |
| Design Temperature | -20~50ºC |
| Design Pressure | 1.61 Mpa |
| Corrosion Allowance | 1 mm |
| Major Materials of Bearing Pressure | Tanker body:Q345, 12mm |
| End plate:Q345R, 12mm,double ellipse | |
| Main beam:16Mn | |
| Detection | |
| Heat Treatment | Overall treatment in a furnace,600ºCto 640ºC |
| Flaw Detection | 100% Flaw detection |
| Test Pressure | 1.61Mpa |
| Hydraulic Test | 2.1Mpa |
| Magnaflux inspection | Aim at welding place thatflaw detection can not cover |
| Manhole(As customer's requirement) | 1, on top |
| Safety Valve(As customer's requirement) | 1, on top |
| Running system | |
| Axles | 3*13TFuwa brand |
| Suspension | Mechanical suspension |
| Tire | 12R22.5 Tubeless tire,13 including one spare tire |
| Pneumatic Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 45L air tanks. |
| Landing leg | JOST brand, two-speed, manual operating |
| King Pin | 3.5 inch |
Truck picture:
Application:
LPG truck is used to transport liquefied petroleum gas, such as propane, liquid ammonia, dimethyl ether (DME), isobutene, etc.
Details :
Loading :
Customer visit:
