1000L Split Pressurized Buffer Tank

Product Description

1000L Split Pressurized Buffer Tank Product Description
The buffer tank is designed to be incorporated into a space heating circuit, increasing the volume of water in the heating system. This additional water volume is intended to protect the heat pump compressor from short cycling which can lead to higher running costs, damage to the heat pump, a reduction in its working life and lower energy efficiency performance. Additionally, it helps protect the heat pump by assisting defrost cycles and improves the heating system response times.
Suitable for the primary heating circuit of both open vented or sealed system (6 Bar maximum pressure)
Improved comfort levels as heating system can be fully controlled and zoned
Reduces or eliminates short cycling of the heat pump
Prevents water in the system from getting colder during heat pump defrost cycles
Future-proofs the heat pump system for smart electricity meters with flexible energy tariffs
Manufactured from SUS 304/ SUS316L stainless steel for superior corrosion resistance
50mm thickness of environmentally-friendly foam lagging for low standing heat loss

Product Parameters

CAPACITY (L)	60L	100L	150L	200L	300L	400L	500L	600L	800L	1000L
Max work pressure (Mpa)	0.6
Inner tank diameter (mm)	φ365	φ365	φ365	φ440	φ480	φ600	φ600	φ600	φ850	φ900
Outer tank diameter (mm)	φ470	φ470	φ470	φ540	φ600	φ700	φ700	φ700	φ750	φ1000
Inner tank material	SUS304-2B/316L 1.2mm	SUS304-2B/316L 1.2mm	SUS304-2B/316L 1.2mm	SUS304-2B/316L 1.2mm	SUS304-2B/316L 1.2mm	SUS304-2B/316L 2.0mm	SUS304-2B/316L 2.0mm	SUS304-2B/316L 2.0mm	SUS304-2B/316L 2.0mm	SUS304-2B/316L 2.0mm
Outer tank material	Painted galvanized steel 0.5mm / SUS 3042B0.5 mm / SUS316L 0.5 mm
Insulation thickness PU (mm)	52.5	52.5	52.5	50	60	50	50	50	50	50
Rated heating power (option)	1.5KW	1.5KW	1.5KW	2.5KW	2.5KW	2.5KW	3KW	3KW	3KWX2	3KWX2
Mag Rod (option)	200mm	200mm	200mm	200mm	290mm	290mm	290mm	290mm	290mm	290mm
Circulation	G3/4 Femal	G3/4 Femal	G3/4 Femal	G3/4 Femal	G1 Femal	G1 Femal	G1 Femal	G1 Femal	G1 1/2 Femal	G1 1/2 Femal
Inlet/outlet	G3/4 Femal	G3/4 Femal	G3/4 Femal	G3/4 Femal	G1 Femal	G1 Femal	G1 Femal	G1 Femal	G1 1/2 Femal	G1 1/2 Femal
Backwater	G1/2 Femal	G1/2 Femal	G1/2 Femal	G1/2 Femal	G1/2 Femal	G1/2 Femal	G1/2 Femal	G1/2 Femal	G3/4 Femal	G3/4 Femal
Overall dimension (references) (mm)	φ470*670	φ470×1150	φ470*1480	φ540×1470	φ600×1790	φ700×1450	φ700×1790	φ700*2130	φ850*2000	φ1000*1820
Packing case size (mm)	700*500*500	1090*500*500	1510*500*500	1560×590×590	1860×650×650	1530×750×750	1870×750×750	2210*750*750	2080*900*900	1900*1050*1050
