2023 Aluminum Straight Edge Ruler Measuring Tool
Basic Info.
Model NO.
100*100~3000*8000mm
Type
Inspection Surface Plate
Material
Aluminum Alloy
Measurement Object
Flatness
Range
0～500mm
Resolution
0.01mm
Precision
0.01mm
Measure Method
Manual
Accuracy
A
Precision Measuring Device
Precision Measuring Device
Certification
CE, ISO
Customized
Customized
Accessory
Stand
Usage
Inspection
Shipping
Sea
Transport Package
Wooden Package
Specification
Can be customized
Trademark
huawei
Origin
China
Production Capacity
1000 Piece/Month
Product Description
2023 Aluminum straight edge ruler measuring tool| The specification | |
| Standard | GB/6092-85 |
| Material | HT200-250 |
| Precision | 0,1,2,3 Grade |
| Size(L*W*H) | 500*60*30-6000*175*80mm or customized |
| Weight | 1kgs-120kgs |
| Working environment temperature | (20±5)ºC |
A.Cast iron straight edge is used to test the straightness and flatness of workpiece and equipment installing.
B.Straight edges are also used for blue matching during hand scrapping operations&have wide and parallel working surface for application of spirit level.
C.According to standard JB/T7977-99
D.Working surface made by scraping or grinding.
E.Working environment temperature is (20±5)°C.
F.If you want other size of cast iron straight edge ,we can produce the edges according to your drawing.
Granite surface plate has the following characteristics:
| 1. | High quality with competitive prices. |
| 2. | Rust-proof technology has obtained a patent. |
| 3. | Factory with more than 70 years' experience. |
| 4. | Professional design and strong production capacity. |
